Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM

Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM
Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM

Large Image :  Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM

Product Details:
Place of Origin: China
Brand Name: QYT
Certification: IP66 IP69K CE ROHS FCC
Model Number: EFIC-6000JB
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: 1pc/carton, weight: 4kg/pc,Packing Size:360 x 180 x 320 mm
Delivery Time: 3 working days upon receive the payment
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Piece/Pieces per Month

Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM

Description
CPU: Intel Celeron Quad Core J1900 2.0GHz Waterproof Rate: IP66 / IP67 / IP69K
Memory: 4GB/8GB/16GB Storage: 32G SSD/64G SSD/128G SSD
Storage Temperature: -20~80°C(-22~176°F) System: Windows7 / 8 / 10, Linux, Unix, QNX
Power Consumption: ≦15W LAN: 1 X LAN ( Optional )
USB: 2 X USB2.0 / 2 X USB3.0 ( Optional ) COM: 2 X RS232 ( Optional )
Highlight:

Ubuntu Industrial Embedded Box PC

,

3G outdoor pc

,

GPS linux box pc

Outdoor Embedded Linux Ubuntu Mini Computer With 3G WIFI GPS COM



The waterproof pc is ideal for applications such as marine/Sailing boat, medical equipment, humid production equipment, food Industry, chemical manufacturing and other outdoor applications.



Features:

1. Aluminium alloy shell, whole pc IP66/ IP67/IP69K waterproof


2. Intel Celeron 4305U Duad Core 2.1GHz, Embedded mini Computer

3. Multi ports for option: VGA/HD-MI/LAN/USB/COM

4. Operating System: Win7/8/10/Linux/Ubuntu

5. DC12V~24V Input,(+9V~36V)wide voltage input optional


Applications
The waterproof computers are a great solution for food and beverage processing, agriculture and automation control where the computers are in constant threat of water splash from all directions to even water immersion.



Specification

EFIC-6000JB
System CPU Intel Celeron Quad Core J1900 2.0GHz
L2 Cache 2MB
Chipsets Intel Bay Trail SOC
Memory DDR3L 1333MHz 4GB, Up to 8GB
Harddisk 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
Graphics Intel HD Graphics
Network Intel 82583V 1000 Mbps port
Audio Realtek ACL662 Audio controller
Operation System Windows7 / 8 / 10, Linux, Unix, QNX
I / O VGA 1 x VGA / 1 x HD-MI ( Optional )
LAN 1 x LAN ( Optional )
USB 2 x USB2.0 / 1 x USB3.0 ( Optional )
COM 2 x RS232 ( Optional )
Wireless Network WiFi + Bluetooth ( Optional )
Other I/O Interface 1 x Power Switch
Institutional Material Aluminum Alloy Shell
Color Silver / Black ( optional )
VESA Mounting VESA: 100 x 100 mm
Waterproof Rate IP66 / IP67 / IP69K
Product Dimension 220 x 180 x 55 mm
Cut-out Size /
Packing Size 360 x 180 x 320 mm
Gross Weight 4.0 KG
Power and Environment Operating Temperature -10~60°C
Storage Temperature -20~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC 12V~24V / optional(+9V~36V)
Power Consumption ≦15W



Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM 0Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM 1Outdoor Linux Ubuntu Industrial Embedded Box PC With 3G WIFI GPS COM 2



Highly reliable, fanless, noise-free, energy efficient, rugged mini PC designed for a large variety of demanding applications. Designed without cooling fans the rugged extruded aluminum chassis acts as a heat sink to dissipate internal heat and provide quiet noise free operation. A breakthrough in micro computing thanks to the rugged design, compact dimensions, and high functionality.
Shinho Fanless Rugged Mini PCs series are designed for unique, industrial applications that require compact size, durability, high reliability, and universal performance.
