Ip66 Waterproof Flat Touch Screen Computers , Outdoor 19" Fanless Hmi Panel Pc
19" full flat touch screen ip66 waterproof panel pc, outdoor fanless hmi panel pc Feature The waterproof computers are a great solution for food and beverage processing, agriculture and automation control where the computers are in constant threat of water splash from all directions to even water immersion. 1. 19" TFT LED, resolution 1280 x 1024 2. 10 points capacitive touch screen, high precision, durable, anti-interference. 3. Intel Bay trail j1900 CPU: 2.0GHz, industrial
hmi flat touch screen computers
,19" flat touch screen computers
,Ip66 hmi panel pc
19" full flat touch screen ip66 waterproof panel pc, outdoor fanless hmi panel pc
Feature
The waterproof computers are a great solution for food and beverage processing, agriculture and automation control where the computers are in constant threat of water splash from all directions to even water immersion.
1. 19" TFT LED, resolution 1280 x 1024
2. 10 points capacitive touch screen, high precision, durable, anti-interference.
3. Intel Bay trail j1900 CPU: 2.0GHz, industrial panel pc ip66
4. Multi I/O Interface optional: VGA/HD-MI/LAN/USB/RS232
5. OS: Win7/8/10/Linux/Ubuntu
6. DC12V~24V Input,(+9V～36V)wide voltage input optional
| WPC-J019SAC | ||
| System | CPU | Intel Celeron Quad Core J1900 2.0GHz |
| L2 Cache | 2MB | |
| Chipsets | Intel Bay Trail SOC | |
| Memory | DDR3L 1333MHz 4GB, Up to 8GB | |
| Harddisk | 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional | |
| Graphics | Intel HD Graphics | |
| Network | Intel 82583V 1000 Mbps port | |
| Audio | Realtek ACL662 Audio controller | |
| Operation System | Windows7 / 8 / 10, Linux, Unix, QNX | |
| I / O | VGA | 1 x VGA / 1 x HD-MI ( Optional ) |
| LAN | 1 x LAN ( Optional ) | |
| USB | 3 x USB2.0 / 1 x USB3.0 ( Optional ) | |
| COM | 2 x RS232 ( Optional ) | |
| Wireless Network | WiFi + Bluetooth ( Optional ) | |
| Other I/O Interface | 1 x Power Switch | |
| LCD Panel | Panel Size | 19" Led |
| Resolution | 1280 x 1024 | |
| Aspect Ratio | 4:3 | |
| Display Brightness | 450 cd/m2 | |
| Contrast Ratio | 1000:1 | |
| Colors | 16.7M , 90% NTSC | |
| Response Time | 7/3 (Typ.)(Tr/Td) ms | |
| Viewing Angle | 85 / 85 / 80 / 80 (CR≥10) ( L / R / U / D ) | |
| Touch screen | Touch Screen Type | 10 point capacitive touch |
| Transmittance | >90% | |
| Response Time | <5ms | |
| Surface Hardness | ≥6H | |
| Supply Voltage | 5.0V DC | |
| Touch Life | ≧ 3000W | |
| Institutional | Material | Aluminum Alloy Shell |
| Color | Silver / Black ( optional ) | |
| VESA Mounting | VESA: 100 x 100 mm | |
| Waterproof Rate | IP66 / IP69K | |
| Product Dimension | 427 x 352 x 40 mm | |
| Cut-out Size | / | |
| Packing Size | 500 x 180 x 450 mm | |
| Gross Weight | 8.0 KG | |
| Power and Environment | Operating Temperature | -10~60°C |
| Storage Temperature | -20~80°C(-22~176°F) | |
| Relative Humidity | 5%~95%@40°C, non-condensing | |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A | |
| Working Voltage | DC 12V~24V / optional(+9V~36V) | |
| Power Consumption | ≦30W | |
Packing List
WPC-J019SAC Waterproof Panel PC
Waterproof VGA/RS232/LAN/USB/COM cables
1x Utility DVD Driver
1x Power Adaptor
Applications
Industrial automation
human Machine Interface
Marine control system
welding industry
supervisory control
numerical control device
