Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen

Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen
Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen

Large Image :  Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen

Product Details:
Place of Origin: China
Brand Name: QYT
Certification: CE ROHS IP65 FCC
Model Number: PPC-M008SAR
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Foam + Carton
Delivery Time: 3-5 working days
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Piece/Pieces per Month

Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen

Description
Size: 8.4" Resolution: 800 X 600
CPU: Intel Celeron Dual Core 3855U 1.6GHz Memory: DDR3L 1333MHz 4GB, Up To 8GB
Harddisk: 1 X MSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional Touchscreen: 5 Wire Resistive Touch
I/O: 1*VGA ,1*HD-MI,2*USB2.0 / 2*USB3.0,1*LAN,WiFi + Bluetooth ( Optional ) VESA Mounting: 100 X 100 Mm
Waterproof Rate: IP65 Stock: Yes
High Light:

Linux Celeron Industrial Fanless Mini PC

,

AIO Industrial Fanless Mini PC

,

3855U aio touch screen pc

Linux Celeron Dual Core 3855U AIO Touch Panel PC LCD Computer DC 12V 30W



1.8.4" TFT LED, resolution 800 x 600, resistive touch


2. Intel Celeron 3855U CPU: 1.6GHz, Intel Celeron J1900 or Core 6th/7th I3/I5/I7

3. Multi ports for option: VGA/HD-MI/LAN/USB

4. Operating System: Win7/8/10/Linux/Ubuntu

5. DC12V~19V Input,(+9V~36V)wide voltage input optional



Feature
1. Front bezel aluminum alloy brushed metal craft, seamless design, front panel IP65 waterproof and dustproof.
2. Industrial LCD panel, wide viewing angle, high nits, true color.
3. Adopt multi-points PCAP touch panel, high sensitive and fast-response.
4. High performance motherboard, 7x24 continuous operation.
5. Support wall mounting, embedded mounting, desk stand mouting etc.

6. With 2.0 mega-pixel Camera, Support infrared night vision function.
7. With finger print and RFID reader(125KHz).
8. WIFI(Intel AC7260HMW) and Bluetooth.



Specification

PPC-M008SAR
System CPU Intel Celeron Dual Core 3855U 1.6GHz
L2 Cache 3MB
Chipsets Intel 6th Skylake-U SOC
Memory DDR4L 2133MHz 4GB, Up to 16GB
Harddisk 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
Graphics Intel HD Graphics 520
Network Intel® i211 1000 Mbps port
Audio Realtek ACL662 Audio controller
Operation System Windows7 / 8 / 10, Linux, Unix, QNX
I / O VGA 1 x VGA
Digital signal 1 x HD-MI
USB 2 x USB2.0 / 2 x USB3.0
LAN 1 x LAN
Wireless Network WiFi + Bluetooth ( Optional )
Other I/O Interface 1 x Power Switch
LCD Panel Panel Size 8.4" Led
Resolution 800 x 600
Aspect Ratio 4:3
Display Brightness 450 cd/m2
Contrast Ratio 600:1
Colors 262K/16.2M , 40% NTSC
Response Time 20/10 (Typ.)(Tr/Td) ms
Viewing Angle 80 / 80 / 80 / 60 (CR≥10) ( L / R / U / D )
Touch screen Touch Screen Type 5 wire resistive touch
Transmittance >85%
Response Time <5ms
Surface Hardness ≥3H
Supply Voltage 5.0V DC
Touch Life ≧ 1000W
Institutional Material Aluminum Alloy Panel + Sheet Metal Back Cover, Baking Varnish Treated
Color Silver / Black ( optional )
VESA Mounting VESA: 100 x 100 mm
Waterproof Rate IP65
Product Dimension 235 x 185 x 55 mm
Cut-out Size 221 x 171 mm
Packing Size 360 x 180 x 320 mm
Gross Weight 4.0 KG
Power and Environment Operating Temperature -10~60°C
Storage Temperature -20~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC 12V~19V / optional(+9V~36V)
Power Consumption ≦30W



Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen 0Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen 1Linux Celeron Industrial Fanless Mini PC Dual Core 3855U AIO Touch Screen 2

Application

manufacturing

industrial automation

medical, semiconductor

food processing

machine control


FAQ
1. Q: Are you a manufacturer or trading company?
A: We're a professional manufacturer with more than 10 years experience in industrial automation field.
2. Q: Do you provide ODM/OEM or customized service?
A: Yes,we support OEM&ODM service, let you get the products you want exactly.
3. Q: What certifications do you have?
A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.
4. Q: How long is the warranty?
A: Our factory promised warranty is 1 year.
5. Q:What is the lead time?
A: 3 business days for samples order, 15 business days for mass production.
6. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
