Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use

Certification
China QYT industry Co.,Ltd certification
China QYT industry Co.,Ltd certification
Customer Reviews
I use these industrial embedded box pc for machine control, they work great, and the fanless design is a huge plus in an environment where small metal particles are everywhere. The Wi-Fi reception is excellent, continuous work, wide voltage DC 9V~36V and reverse connection protection, as in description, everything works perfect, good communication.

—— Lacroix Philippe

Great industrial touch panel pc easy to work with and well constructed, fast delivery, with windows 10, TPM2.0 Provide a secure encryption key. our equipment needed multiple USB inputs . And if I need to ever control any external devices by RS232 or RS422 or RS485 ports opens up so many possibilities. nice product, I highly recommend it.

—— Roy Smith

I'm Online Chat Now

Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use

Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use
Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use

Large Image :  Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use

Product Details:
Place of Origin: Guangdong, China
Brand Name: QYT
Certification: CE, FCC, RoHS, IP66, IP69K
Model Number: WPC-J019SAC
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Foam + Carton
Delivery Time: 3-10 Business Days
Payment Terms: T/T, L/C, Western Union, MoneyGram, D/A, D/P
Supply Ability: 5000 Set/Sets per Month

Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use

Description
Waterproof Rating: IP66 / IP69K Size: 19" Led
Resolution: 1280 X 1024 Processor: Intel Celeron Quad Core J1900 2.0GHz
Memory: 4GB, Up To 8GB HDD: 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
I/O Interface: VGA/HD-MI/LAN/USB/COM Touchscreen Panel: Capacitive / Resistive Touch Optional
Power Input: DC 12V~24V / DC 9V~36V Optional Operating System: Win7/8/10/Linux/Ubuntu
High Light:

VESA IP67 Panel PC

,

Fanless IP67 Panel PC

,

IP67 industrial touch panel pc

19" Industrial Touch Panel Pc IP67 Waterproof Outdoor Fanless Wall Mount VESA

Feature
The waterproof computers are a great solution for food and beverage processing, agriculture and automation control where the computers are in constant threat of water splash from all directions to even water immersion.


1. 19" TFT LED, resolution 1280 x 1024

2. 10 points capacitive touch screen, high precision, durable, anti-interference.


3. Intel Bay trail j1900 CPU: 2.0GHz, industrial panel pc ip66

4. Multi I/O Interface optional: VGA/HD-MI/LAN/USB/RS232

5. OS: Win7/8/10/Linux/Ubuntu

6. DC12V~24V Input,(+9V~36V)wide voltage input optional

7. Fully sealed and fanless design, full IP69k waterproof, Sealed I/O with cable set included.

WPC-J019SAC
SystemCPUIntel Celeron Quad Core J1900 2.0GHz
L2 Cache2MB
ChipsetsIntel Bay Trail SOC
MemoryDDR3L 1333MHz 4GB, Up to 8GB
Harddisk1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
GraphicsIntel HD Graphics
NetworkIntel 82583V 1000 Mbps port
AudioRealtek ACL662 Audio controller
Operation SystemWindows7 / 8 / 10, Linux, Unix, QNX
I / OVGA1 x VGA / 1 x HD-MI ( Optional )
LAN1 x LAN ( Optional )
USB3 x USB2.0 / 1 x USB3.0 ( Optional )
COM2 x RS232 ( Optional )
Wireless NetworkWiFi + Bluetooth ( Optional )
Other I/O Interface1 x Power Switch
LCD PanelPanel Size19" Led
Resolution1280 x 1024
Aspect Ratio4:3
Display Brightness450 cd/m2
Contrast Ratio1000:1
Colors16.7M , 90% NTSC
Response Time7/3 (Typ.)(Tr/Td) ms
Viewing Angle85 / 85 / 80 / 80 (CR≥10) ( L / R / U / D )
Touch screenTouch Screen Type10 point capacitive touch
Transmittance>90%
Response Time<5ms
Surface Hardness≥6H
Supply Voltage5.0V DC
Touch Life≧ 3000W
InstitutionalMaterialAluminum Alloy Shell
ColorSilver / Black ( optional )
VESA MountingVESA: 100 x 100 mm
Waterproof RateIP66 / IP69K
Product Dimension427 x 352 x 40 mm
Cut-out Size/
Packing Size500 x 180 x 450 mm
Gross Weight8.0 KG
Power and EnvironmentOperating Temperature-10~60°C
Storage Temperature-20~80°C(-22~176°F)
Relative Humidity5%~95%@40°C, non-condensing
Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power SupplyAC 100 - 240V~50/60Hz,1.5A
Working VoltageDC 12V~24V / optional(+9V~36V)
Power Consumption≦30W


Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use 0
Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use 1Wall Mount VESA 19 Inch IP67 Panel PC Industrial Touch Fanless Outdoor Use 2
Packing List
WPC-J019SAC Waterproof Panel PC

Waterproof VGA/RS232/LAN/USB/COM cables

1x Utility DVD Driver

1x Power Adaptor

Applications

Industrial automation

human Machine Interface

Marine control system

welding industry

supervisory control

numerical control device


FAQ
1. Q: Are you a manufacturer or trading company?
A: We're a professional manufacturer with more than 10 years experience in industrial automation field.
2. Q: Do you provide ODM/OEM or customized service?
A: Yes,we support OEM&ODM service, let you get the products you want exactly.
3. Q: What certifications do you have?
A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.
4. Q: How long is the warranty?
A: Our factory promised warranty is 1 year.
5. Q:What is the lead time?
A: 3 business days for samples order, 15 business days for mass production.
6. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
