IP69K Embedded Capacitive Touch Monitor 13.3" Stainless Washable 1920*1080

IP69K Embedded Capacitive Touch Monitor 13.3" Stainless Washable 1920*1080
IP69K Embedded Capacitive Touch Monitor 13.3" Stainless Washable 1920*1080 IP69K Embedded Capacitive Touch Monitor 13.3" Stainless Washable 1920*1080 IP69K Embedded Capacitive Touch Monitor 13.3" Stainless Washable 1920*1080

Large Image :  IP69K Embedded Capacitive Touch Monitor 13.3" Stainless Washable 1920*1080

Product Details:
Place of Origin: Shenzhen, China
Brand Name: QYT
Certification: CE, FCC, RoHS
Model Number: WPM-H133WCC
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Foam + Carton
Delivery Time: 3-10 Business Days
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Set/Sets per Month

IP69K Embedded Capacitive Touch Monitor 13.3" Stainless Washable 1920*1080

Description
IP Rating: IP66 / IP69K Size: 13.3"
Screen: 10 Points PCAP Touch Resolution: 1920 X 1080
Aspect Ratio: 16:9 Viewing Angle: 85 / 85 / 85 / 85 (CR≥10) ( L / R / U / D )
Display Brightness: 400 Cd/m2 I/O Input: 1*HDMI, 1*T-USB
Material: Stainless Steel Panel
Highlight:

IP69K Embedded Capacitive Touch Monitor

,

13.3" Capacitive Touch Monitor

,

Stainless Washable Capacitive Touchscreen Display

13.3" Stainless Washable IP69K Embedded Mounting Capacitive Touch For Industrial Application 1920*1080

Feature

The Stainless Steel Monitor Line are industrial-grade systems designed to perform in critical environments that call for a greater level of resistance to corrosion such as found in pharmaceutical, chemical or food factories.



1. Stainless Steel Panel, Full IP66 / IP69K Waterproof

2. 13.3" TFT LED, resolution 1920*1080, 10 points capacitive touch

3. HD-MI/VGA/DVI multiple signals input supported

4. Embedded / VESA mounting

5. DC12V Input, (+9V~36V) wide voltage input optional

6. Support wall mounting, embedded mounting, desk stand mouting etc.

7. Accept customization

8. -20C to +70°C Wide temperature support.

WPM-H133WCC
LCD Panel Panel Size 13.3" FHD Led
Resolution 1920 x 1080
Aspect Ratio 16:9
Display Brightness 400 cd/m2
Contrast Ratio 900:1
Colors 16.7M , 86% NTSC
Backlight Lifetime 50000 Hr (min.)
Viewing Angle 85 / 85 / 85 / 85 (CR≥10) ( L / R / U / D )
Touch screen Touch Screen Type Multi-Touch PCAP
Transmittance >90%
Response Time <5ms
Surface Hardness ≥6H
Supply Voltage 5.0V DC
Touch Life ≧ 3000W
I / O H-DMI 1 x H-DMI
USB 1 x Touch USB
Other I/O Interface 1 x Power Switch
Institutional Material Stainless Steel Panel
Color Natural
VESA Mounting VESA: 100 x 100 mm
Waterproof Rate IP66 / IP69K
Product Dimension 350 x 234 x 55 mm
Cut-out Size
Packing Size 460 x 180 x 400 mm
Gross Weight 7 KG
Power and Environment Operating Temperature -20~70°C
Storage Temperature -30~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC 12V / optional(+9V~36V)


IP69K Embedded Capacitive Touch Monitor 13.3" Stainless Washable 1920*1080 0IP69K Embedded Capacitive Touch Monitor 13.3" Stainless Washable 1920*1080 1

Application
The stainless steel monitors are suitable for humid or watered environment, such as food processing industry, catering, production workshop, outdoor, or some other harsh environment.




Our Advantage

1. Experience

QYT has more than 10 years rich experience in Industrial Computer/monitor filed.



2. Wide products line

7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android pc...etc.which have excellent work performane.



3. Customization functions

It offers rich of interface to meet csutomers needs.



4.Widely useage environment

QYT computer/monitor which is widly used for kitchen,food industry, boat...etc
