Product Details:
|
| IP Rating: | IP66 / IP69K | Size: | 13.3" |
|---|---|---|---|
| Screen: | 10 Points PCAP Touch | Resolution: | 1920 X 1080 |
| Aspect Ratio: | 16:9 | Viewing Angle: | 85 / 85 / 85 / 85 (CR≥10) ( L / R / U / D ) |
| Display Brightness: | 400 Cd/m2 | I/O Input: | 1*HDMI, 1*T-USB |
| Material: | Stainless Steel Panel | ||
| Highlight: | Sus304 IP69K Panel PC,Washable IP69K Panel PC,Ip66 Embedded Panel PC |
||
Feature
The Stainless Steel Monitor Line are industrial-grade systems designed to perform in critical environments that call for a greater level of resistance to corrosion such as found in pharmaceutical, chemical or food factories.
| WPM-H133WCC | ||
| LCD Panel | Panel Size | 13.3" FHD Led |
| Resolution | 1920 x 1080 | |
| Aspect Ratio | 16:9 | |
| Display Brightness | 400 cd/m2 | |
| Contrast Ratio | 900:1 | |
| Colors | 16.7M , 86% NTSC | |
| Backlight Lifetime | 50000 Hr (min.) | |
| Viewing Angle | 85 / 85 / 85 / 85 (CR≥10) ( L / R / U / D ) | |
| Touch screen | Touch Screen Type | Multi-Touch PCAP |
| Transmittance | >90% | |
| Response Time | <5ms | |
| Surface Hardness | ≥6H | |
| Supply Voltage | 5.0V DC | |
| Touch Life | ≧ 3000W | |
| I / O | H-DMI | 1 x H-DMI |
| USB | 1 x Touch USB | |
| Other I/O Interface | 1 x Power Switch | |
| Institutional | Material | Stainless Steel Panel |
| Color | Natural | |
| VESA Mounting | VESA: 100 x 100 mm | |
| Waterproof Rate | IP66 / IP69K | |
| Product Dimension | 350 x 234 x 55 mm | |
| Cut-out Size | ||
| Packing Size | 460 x 180 x 400 mm | |
| Gross Weight | 7 KG | |
| Power and Environment | Operating Temperature | -20~70°C |
| Storage Temperature | -30~80°C(-22~176°F) | |
| Relative Humidity | 5%~95%@40°C, non-condensing | |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A | |
| Working Voltage | DC 12V / optional(+9V~36V) | |
Application
The stainless steel monitors are suitable for humid or watered environment, such as food processing industry, catering, production workshop, outdoor, or some other harsh environment.
Our Advantage
1. Experience
QYT has more than 10 years rich experience in Industrial Computer/monitor filed.
2. Wide products line
7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android pc...etc.which have excellent work performane.
3. Customization functions
It offers rich of interface to meet csutomers needs.
4.Widely useage environment
QYT computer/monitor which is widly used for kitchen,food industry, boat...etc
FAQ
1. Q: Are you a manufacturer or trading company?
A: We're a professional manufacturer with more than 10 years experience in industrial automation field.
2. Q: Do you provide ODM/OEM or customized service?
A: Yes,we support OEM&ODM service, let you get the products you want exactly.
3. Q: What certifications do you have?
A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.
4. Q: How long is the warranty?
A: Our factory promised warranty is 1 year.
5. Q: What is the lead time?
A: 3 business days for samples order, 15 business days for mass production.
6. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
