Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial

Certification
China QYT industry Co.,Ltd certification
China QYT industry Co.,Ltd certification
Customer Reviews
I use these industrial embedded box pc for machine control, they work great, and the fanless design is a huge plus in an environment where small metal particles are everywhere. The Wi-Fi reception is excellent, continuous work, wide voltage DC 9V~36V and reverse connection protection, as in description, everything works perfect, good communication.

—— Lacroix Philippe

Great industrial touch panel pc easy to work with and well constructed, fast delivery, with windows 10, TPM2.0 Provide a secure encryption key. our equipment needed multiple USB inputs . And if I need to ever control any external devices by RS232 or RS422 or RS485 ports opens up so many possibilities. nice product, I highly recommend it.

—— Roy Smith

I'm Online Chat Now

Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial

Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial
Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial

Large Image :  Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial

Product Details:
Place of Origin: Guangdong, China
Brand Name: QYT
Certification: CE, FCC, RoHS, IP66, IP69K
Model Number: WPC-M156WAC
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Foam + Carton
Delivery Time: 3-10 Business Days
Payment Terms: T/T, L/C, Western Union, MoneyGram, D/A, D/P
Supply Ability: 5000 Set/Sets per Month

Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial

Description
Waterproof Rating: IP69K Panel Size: 15.6" Led
Resolution: 1920 X 1080 CPU: Intel Celeron Dual Core 3855U 1.6GHz
Memory: 4GB, Up To 16GB Harddisk: 32G / 64G / 128G / 250G / 500G SSD Optional
I/O Interface: VGA/HD-MI/LAN/USB/RS232 Touchscreen: Capacitive / Resistive Touch Optional
Power Input: DC 12V~24V / DC 9V~36V Optional Operating System: Win7/8/10/Linux/Ubuntu
High Light:

IP69K PCAP Touch Panel PC

,

15.6" PCAP Touch Panel PC

,

PCAP Touch IP69K Panel PC

Outdoor IP69K Linux 15.6" Pcap Touch Screen Panel PC Waterproof Industrial

Waterproof Touch Computers are designed to withstand extreme conditions and operate reliably in the harshest industrial environments. These devices are protected from water, dust and dirt, abrasive substances and extreme temperatures. Designed and engineered to operate in tough 24/7 continuous operation, these units are required for harsh environments.

Engineered with a strong housing and with IP67 rated protected connectors, water resistant computers are made to withstand tough and rugged environments, with models for both indoors and out.



From IP66 to IP68/IP69K (on all sides)

As rugged as it gets – QYT waterproof touchscreen PCs are certified up to protection class IP68/IP69K and can fully withstand the most extreme conditions, including high-pressure cleaning from all sides with 80+ degree hot water.



Fanless Design

With no moving parts, the fanless design feature of the Industrial Computer line offers reliable operation in harsh environments, and dramatically reduces cleaning and maintenance.



Applications



Industrial automation



human Machine Interface



Marine control system



welding industry



supervisory control



numerical control device



WPC-M156WAC
System CPU Intel Celeron Dual Core 3855U 1.6GHz
L2 Cache 2MB
Chipsets Intel Skylake-U SOC
Memory DDR4L 2133MHz 4GB, Up to 16GB
Harddisk 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
Graphics Intel HD Graphics 510
Network Intel® i211 1000 Mbps port
Audio Realtek ACL662 Audio controller
Operation System Windows7 / 8 / 10, Linux, Unix, QNX
I / O VGA 1 x VGA / 1 x HD-MI ( Optional )
LAN 1 x LAN ( Optional )
USB 4 x USB ( Optional )
COM 2 x RS232 ( Optional )
Wireless Network WiFi + Bluetooth ( Optional )
Other I/O Interface 1 x Power Switch
LCD Panel Panel Size 15.6" Led
Resolution 1920 x 1080
Aspect Ratio 16:9
Display Brightness 450 cd/m2
Contrast Ratio 800:1
Colors 16.2M , 72% NTSC
Response Time 13/12 (Typ.)(Tr/Td) ms
Viewing Angle 85 / 85 / 85 / 85 (CR≥10) ( L / R / U / D )
Touch screen Touch Screen Type 10 point capacitive touch
Transmittance >90%
Response Time <5ms
Surface Hardness ≥6H
Supply Voltage 5.0V DC
Touch Life ≧ 3000W
Institutional Material Aluminum Alloy Shell
Color Silver / Black ( optional )
VESA Mounting VESA: 100 x 100 mm
Waterproof Rate IP66 / IP69K
Product Dimension 398 x 247 x 52 mm
Cut-out Size /
Packing Size 460 x 180 x 400 mm
Gross Weight 7.0 KG
Power and Environment Operating Temperature -10~60°C
Storage Temperature -20~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC 12V~24V / optional(+9V~36V)
Power Consumption ≦30W


Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial 0Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial 1Outdoor IP69K Linux PCAP Touch Panel PC 15.6" Waterproof Industrial 2
