Product Details:
|
| Waterproof Rating: | IP66 / IP69K | Size: | 19" Led |
|---|---|---|---|
| Resolution: | 1280 X 1024 | Processor: | Intel Celeron Quad Core J1900 2.0GHz |
| Memory: | 4GB, Up To 8GB | HDD: | 32G SSD / (64G / 128G / 250G / 500G SSD) Optional |
| I/O Interface: | VGA/HD-MI/LAN/USB/COM | Touchscreen Panel: | Capacitive / Resistive Touch Optional |
| Power Input: | DC 12V~24V / DC 9V~36V Optional | Operating System: | Win7/8/10/Linux/Ubuntu |
| High Light: | IP66 Embedded Industrial Panel PC,1280 x 1024 Waterproof Touch Screen PC |
||
Feature
QYT's WPC series is a high performance rugged Waterproof PC computer that is completely sealed, surviving liquids, chemicals, dust and dirt intrusion and meeting IP69K environmental specifications.
This durable environmentally sealed Panel PC features a powerful Intel Core i3/i5 Processor, solid state drives (SSD) and operates from a wide range of DC input power (9 – 36VDC) making it a perfect fit for demanding applications within the Industrial, Commercial, Scientific Research, Military, Public Safety, Utility, Marine, Transportation, Mining and Telecommunications markets.
QYT specializes in both designing and manufacturing waterproof PCs – part of our line of rugged and hazardous computers. You might be wondering what makes them both rugged and waterproof?
Our waterproof computers are housed in IP69K enclosures, making them suitable for outdoor use. They have superior protection against wind and rain, dust, splashing water and corrosion.
High levels of moisture, spray and the presence of corrosive chemicals or dust destroy most computers and their internal components. We have witnessed many computers that are vital to the productivity in manufacturing facilities fail under wet, corrosive dusty conditions. Solutions are nearly impossible to find, but QYT offers mills and other industrial facilities a one-of-a-kind solution — a completely sealed waterproof PC.
The waterproof pc is ideal for applications such as marine/Sailing boat, medical equipment, humid production equipment, food Industry, chemical manufacturing and other outdoor applications.
Product Advantage
1. Robust aluminum alloy/stainless steel enclosure, sealed I/O from particles, water, and corrosive agents
2. Full IP66/69K sealed to providing 360 degree protection
3. Windows-based with integrated CPU, RAM, storage, USB, RS232, and LAN ports
4. Flexible, reliable, and rugged for open platform HMI/SCADA
5. Provides improved power efficiency and reduced consumption
6. CE, FCC, RoHS, IP69K Compliance
| WPC-J019SAC | ||
| System | CPU | Intel Celeron Quad Core J1900 2.0GHz |
| L2 Cache | 2MB | |
| Chipsets | Intel Bay Trail SOC | |
| Memory | DDR3L 1333MHz 4GB, Up to 8GB | |
| Harddisk | 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional | |
| Graphics | Intel HD Graphics | |
| Network | Intel 82583V 1000 Mbps port | |
| Audio | Realtek ACL662 Audio controller | |
| Operation System | Windows7 / 8 / 10, Linux, Unix, QNX | |
| I / O | VGA | 1 x VGA / 1 x HD-MI ( Optional ) |
| LAN | 1 x LAN ( Optional ) | |
| USB | 3 x USB2.0 / 1 x USB3.0 ( Optional ) | |
| COM | 2 x RS232 ( Optional ) | |
| Wireless Network | WiFi + Bluetooth ( Optional ) | |
| Other I/O Interface | 1 x Power Switch | |
| LCD Panel | Panel Size | 19" Led |
| Resolution | 1280 x 1024 | |
| Aspect Ratio | 4:3 | |
| Display Brightness | 450 cd/m2 | |
| Contrast Ratio | 1000:1 | |
| Colors | 16.7M , 90% NTSC | |
| Response Time | 7/3 (Typ.)(Tr/Td) ms | |
| Viewing Angle | 85 / 85 / 80 / 80 (CR≥10) ( L / R / U / D ) | |
| Touch screen | Touch Screen Type | 10 point capacitive touch |
| Transmittance | >90% | |
| Response Time | <5ms | |
| Surface Hardness | ≥6H | |
| Supply Voltage | 5.0V DC | |
| Touch Life | ≧ 3000W | |
| Institutional | Material | Aluminum Alloy Shell |
| Color | Silver / Black ( optional ) | |
| VESA Mounting | VESA: 100 x 100 mm | |
| Waterproof Rate | IP66 / IP69K | |
| Product Dimension | 427 x 352 x 40 mm | |
| Cut-out Size | / | |
| Packing Size | 500 x 180 x 450 mm | |
| Gross Weight | 8.0 KG | |
| Power and Environment | Operating Temperature | -10~60°C |
| Storage Temperature | -20~80°C(-22~176°F) | |
| Relative Humidity | 5%~95%@40°C, non-condensing | |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A | |
| Working Voltage | DC 12V~24V / optional(+9V~36V) | |
| Power Consumption | ≦30W | |
Packing List
WPC-J019SAC Waterproof Panel PC
Waterproof VGA/RS232/LAN/USB/COM cables
1x Utility DVD Driver
1x Power Adaptor
OEM/ODM
1. size from 7''-24'' available
2. Processor--Intel J1900/ I3/I5/ .....etc lower consumption board
3. Capacitive touch / Resistive touch or without touch
4. 1000nits, 1500nits high brightness for sunlight readable
5. DC 9V～36V wide voltage input
