Product Details:
|
| Type: | High Pressure IP69K Waterproof HMI Panel PC | Panel Size: | 15" |
|---|---|---|---|
| Resolution: | 1024 X 768 | CPU: | Intel Celeron Quad Core J1900 2.0GHz |
| Memory: | DDR3L 4GB | HDD: | MSATA 32G SSD |
| I/O Interface: | VGA/HDMI/LAN/USB/RS232 | Touchscreen: | 10 Point Capacitive Touch |
| High Light: | High Pressure IP69K HMI Panel PC,Intel Celeron panel pc hmi 1024 x 768,J1900 touch screen industrial hmi panels |
||
High Pressure IP69K Waterproof HMI Panel PC Intel Celeron J1900 touch screen
1. The whole machine is SUS304, in line with IP66/IP69K waterproof standard.
2.15" TFT LED, resolution 1024×768, 10-point capacitive touch.
3. Intel Bay trail j1900 CPU: 2.0GHz fanless waterproof computer.
4. M12 I/O industrial connector optional: VGA/LAN/USB/COM/RS232/RS485.
5. DC 12V~24V power input, optional (+9V~36V) wide voltage input.
Feature
* Fully IP66/IP69K sealed
| WPC-J015SCC | |
| System | |
| CPU | Intel Celeron Quad Core J1900 2.0GHz |
| L2 Cache | 2MB |
| Chipsets | Intel Bay Trail SOC |
| Memory | DDR3L 1333MHz 4GB, Up to 8GB |
| Harddisk | 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional |
| Graphics | Intel HD Graphics |
| Network | Intel 82583V 1000 Mbps port |
| Audio | Realtek ACL662 Audio controller |
| Operation System | Windows7 / 8 / 10, Linux, Unix, QNX |
| I / O | |
| VGA | 1 x VGA / 1 x HD-MI ( Optional ) |
| LAN | 2 x LAN ( Optional ) |
| USB | 3 x USB2.0 / 1 x USB3.0 ( Optional ) |
| COM | 2 x RS232 ( Optional ) |
| Wireless Network | WiFi + Bluetooth ( Optional ) |
| Other I/O Interface | 1 x Power Switch |
| LCD Panel | |
| Panel Size | 15" Led |
| Resolution | 1024 x 768 |
| Aspect Ratio | 4:3 |
| Display Brightness | 350 cd/m2 |
| Contrast Ratio | 1000:1 |
| Colors | 16.7M , 72% NTSC |
| Response Time | 30 (Typ.)(Tr+Td) ms |
| Viewing Angle | 89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D ) |
| Touch screen | |
| Touch Screen Type | 10 point capacitive touch |
| Transmittance | >90% |
| Response Time | <5ms |
| Surface Hardness | ≥6H |
| Supply Voltage | 5.0V DC |
| Touch Life | ≧ 3000W |
| Institutional | |
| Material | Stainless Steel SUS04 |
| Color | Polished brushed surface |
| VESA Mounting | VESA: 100 x 100 mm |
| Waterproof Rate | IP66 / IP69K |
| Product Dimension | 360 x 284 x 55 mm |
| Cut-out Size | / |
| Packing Size | 460 x 180 x 400 mm |
| Gross Weight | 9.0 KG |
| Power and Environment | |
| Operating Temperature | -10~60°C |
| Storage Temperature | -20~80°C(-22~176°F) |
| Relative Humidity | 5%~95%@40°C, non-condensing |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A |
| Working Voltage | DC 12V~24V / optional(+9V~36V) |
| Power Consumption | ≦30W |
Applications
marine/Sailing boat
medical equipment
humid production equipment
food Industry
chemical manufacturing
outdoor applications
Our Advantage
1. Experience
QYT has more than 10 years rich experience in Industrial Computer/monitor filed.
2. Wide products line
QYT possesses 5 series of industrial products, rugged and durable waterproof computer (WPC), highly integrated control HMI (DCP) and embedded fanless industrial panel computer (PPC), embedded industrial computer ( IPC) and embedded fanless industrial computers (EFIC). The product range constantly launches mainstream cost-effective products according to the market demand. Currently there are more than 200 models and other options to serve the market demand.
3. Customization functions
Relying on professional technical capabilities and R&D advantages, QYT creates the most competitive OEM/ODM products according to user demands and industry characteristics.
4.Widely useage environment
QYT pc are widely used in industrial automation, CNC machine, data acquisition, process control, motion control, automated testing, visual inspection, communication gateways and other application fields, as well as rail transit, intelligent transportation, petrochemical, electricity, new energy, medical equipment, environmental monitoring, financial self-service and other industries.
