13.3 Inch Touch Screen Panel PC 6th Gen I3-6100U CPU Waterproof
6th Gen i3-6100U CPU Waterproof 13.3 inch Touch Screen Panel PC 1. Product Features ◆Intel CoreJ1900/ 3855U/I3/I5 series CPU ◆DDR4L 2133MHz 4GB, Up to 16GB ◆1 x M.2 120G SSD / (250G / 500G / 1TB SSD) Optional ◆HDMI/VGA Optional ◆Intel® i211 1000 Mbps port ◆3*USB3.0, 1*USB2.0 (built-in) ◆2 x RS-232 / 422 / 485 Optional ◆support 4G/5G/WIFI/ Bluetooth module ◆DC 12V~24V / optional(+9V~36V) power supply, with anti-reverse connection and over-current protection ◆Stainless Steel
13.3'' Touch Screen Panel PC
,i3-6100U Touch Screen Panel PC
,capacitive touch Waterproof Touch Screen PC
6th Gen i3-6100U CPU Waterproof 13.3 inch Touch Screen Panel PC
1. Product Features
◆Intel CoreJ1900/ 3855U/I3/I5 series CPU
◆DDR4L 2133MHz 4GB, Up to 16GB
◆1 x M.2 120G SSD / (250G / 500G / 1TB SSD) Optional
◆HDMI/VGA Optional
◆Intel® i211 1000 Mbps port
◆3*USB3.0, 1*USB2.0 (built-in)
◆2 x RS-232 / 422 / 485 Optional
◆support 4G/5G/WIFI/ Bluetooth module
◆DC 12V~24V / optional(+9V~36V) power supply, with anti-reverse connection and over-current protection
◆Stainless Steel SUS304, fanless cooling design
| WPC-O133WCC | |
| System | |
| CPU | Intel Core i3-6100U Dual Core 2.4GHz |
| L2 Cache | 3MB |
| Chipsets | Intel 6th Skylake-U SOC |
| Memory | DDR4L 2133MHz 4GB, Up to 16GB |
| Harddisk | 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional |
| Graphics | Intel HD Graphics 520 |
| Network | Intel® i211 1000 Mbps port |
| Audio | Realtek ACL662 Audio controller |
| Operation System | Windows7 / 8 / 10, Linux, Unix, QNX |
| I / O | |
| VGA | 1 x VGA / 1 x HD-MI ( Optional ) |
| LAN | 2 x LAN ( Optional ) |
| USB | 4 x USB ( Optional ) |
| COM | 2 x RS232 ( Optional ) |
| Wireless Network | WiFi + Bluetooth ( Optional ) |
| Other I/O Interface | 1 x Power Switch |
| LCD Panel | |
| Panel Size | 13.3" FHD Led |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Display Brightness | 400 cd/m2 |
| Contrast Ratio | 900:1 |
| Colors | 16.7M , 86% NTSC |
| Response Time | 50000 Hr (min.) |
| Viewing Angle | 85 / 85 / 85 /85 (CR≥10) ( L / R / U / D ) |
| Touch screen | |
| Touch Screen Type | 10 point capacitive touch |
| Transmittance | >90% |
| Response Time | <5ms |
| Surface Hardness | ≥6H |
| Supply Voltage | 5.0V DC |
| Touch Life | ≧ 3000W |
| Institutional | |
| Material | Stainless Steel SUS304 |
| Color | Polished brushed surface |
| VESA Mounting | VESA: 100 x 100 mm |
| Waterproof Rate | IP66 / IP69K |
| Product Dimension | 350 x 234 x 55 mm |
| Cut-out Size | / |
| Packing Size | 460 x 180 x 400 mm |
| Gross Weight | 7.0 KG |
| Power and Environment | |
| Operating Temperature | -10~60°C |
| Storage Temperature | -20~80°C(-22~176°F) |
| Relative Humidity | 5%~95%@40°C, non-condensing |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A |
| Working Voltage | DC 12V~24V / optional(+9V~36V) |
| Power Consumption | ≦25W |
2. About us
Innoyond offers a wide variety of high-performance 13.3-inch high-definition, wide-screen, waterproof industrial touch panel computers. Waterproof computers are used to operate efficiently and reliably in a variety of industrial applications. It integrates an embedded power efficient Intel fanless CPU. It supports industry leading multi-touch PCAP (Projected Capacitive) touch or resistive touch screen, rich I/O including Wifi, Bluetooth, LAN, COM, USB, VGA/HDMI/Display port, built-in speaker. Innoyond's tablet is compatible with Windows7/8/10, Linux, Unix, QNX.
