Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk

Certification
China QYT industry Co.,Ltd certification
China QYT industry Co.,Ltd certification
Customer Reviews
I use these industrial embedded box pc for machine control, they work great, and the fanless design is a huge plus in an environment where small metal particles are everywhere. The Wi-Fi reception is excellent, continuous work, wide voltage DC 9V~36V and reverse connection protection, as in description, everything works perfect, good communication.

—— Lacroix Philippe

Great industrial touch panel pc easy to work with and well constructed, fast delivery, with windows 10, TPM2.0 Provide a secure encryption key. our equipment needed multiple USB inputs . And if I need to ever control any external devices by RS232 or RS422 or RS485 ports opens up so many possibilities. nice product, I highly recommend it.

—— Roy Smith

I'm Online Chat Now

Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk

Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk
Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk

Large Image :  Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk

Product Details:
Place of Origin: China
Brand Name: QYT
Certification: IP66 IP69K CE ROHS FCC
Model Number: EFIC-6001PB
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: 1pc/carton, weight: 4kg/pc,Packing Size:360 x 180 x 320 mm
Delivery Time: 3-7 working days upon receive the payment
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Piece/Pieces per Month

Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk

Description
CPU: Intel Core I5-8265U Quad Core 1.6GHz Waterproof Rate: IP66 / IP67 / IP69K
Memory: 4GB/8GB/16GB Storage: 32G SSD/64G SSD/128G SSD
Material: Aluminum Alloy Shell Storage Temperature: -20~80°C(-22~176°F)
Product Dimension: 220 X 180 X 55 Mm Packing Size: 360 X 180 X 320 Mm
VGA: 1 X VGA / 1 X HD-MI ( Optional ) LAN: 1 X LAN ( Optional )
USB: 2 X USB2.0 / 2 X USB3.0 ( Optional ) COM: 2 X RS232 ( Optional )
High Light:

Quad core Industrial Embedded Box PC

,

RS232 Industrial Embedded Box PC

,

Kiosk embedded mini pc

X86 Intel Core i5-8265U Quad core 1.6GHz LAN 2 RS232 Embedded Mini Pc For Kiosk


Features:

1. Aluminium alloy shell, whole pc IP66/ IP67/IP69K waterproof


2. Intel Core i5-8265U Quad core 1.6GHz, waterproof industrial embedded mini PC

3. Multi ports for option: VGA/HD-MI/LAN/USB/COM

4. Operating System: Win7/8/10/Linux/Ubuntu

5. DC12V~24V Input,(+9V~36V)wide voltage input optional



Highly reliable, fanless, noise-free, energy efficient, rugged mini PC designed for a large variety of demanding applications. Designed without cooling fans the rugged extruded aluminum chassis acts as a heat sink to dissipate internal heat and provide quiet noise free operation. A breakthrough in micro computing thanks to the rugged design, compact dimensions, and high functionality.
Shinho Fanless Rugged Mini PCs series are designed for unique, industrial applications that require compact size, durability, high reliability, and universal performance.



Application

manufacturing

industrial automation

medical, semiconductor

food processing

machine control



Specification

EFIC-6000PB
System CPU Intel Core i5-8265U Quad core 1.6GHz
L3 Cache 6MB
Chipsets Intel 8th Skylake-U SOC
Memory DDR4L 2400MHz 4GB, Up to 32GB
Harddisk 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
Graphics Intel HD Graphics 620
Network Intel® i211A 1000 Mbps port
Audio Realtek ACL662 Audio controller
Operation System Windows 8 / 10, Linux, Unix, QNX
I / O VGA 1 x VGA / 1 x HD-MI ( Optional )
LAN 1 x LAN ( Optional )
USB 2 x USB2.0 / 2 x USB3.0 ( Optional )
COM 2 x RS232 ( Optional )
Wireless Network WiFi + Bluetooth ( Optional )
Other I/O Interface 1 x Power Switch
Institutional Material Aluminum Alloy Shell
Color Silver / Black ( optional )
VESA Mounting VESA: 100 x 100 mm
Waterproof Rate IP66 / IP67 / IP69K
Product Dimension 220 x 180 x 55 mm
Cut-out Size /
Packing Size 360 x 180 x 320 mm
Gross Weight 4.0 KG
Power and Environment Operating Temperature -10~60°C
Storage Temperature -20~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC 9V~36V
Power Consumption ≦20W

Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk 0Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk 1Mini Industrial Embedded Box PC X86 Intel I5-8265U Quad Core RS232 For Kiosk 2


Our Advantage

1. Experience

QYT has more than 10 years rich experience in Industrial Computer/monitor filed.



2. Wide products line

QYT possesses 5 series of industrial products, rugged and durable waterproof computer (WPC), highly integrated control HMI (DCP) and embedded fanless industrial panel computer (PPC), embedded industrial computer ( IPC) and embedded fanless industrial computers (EFIC). The product range constantly launches mainstream cost-effective products according to the market demand. Currently there are more than 200 models and other options to serve the market demand.



3. Customization functions

Relying on professional technical capabilities and R&D advantages, QYT creates the most competitive OEM/ODM products according to user demands and industry characteristics.



4.Widely useage environment

QYT pc are widely used in industrial automation, CNC machine, data acquisition, process control, motion control, automated testing, visual inspection, communication gateways and other application fields, as well as rail transit, intelligent transportation, petrochemical, electricity, new energy, medical equipment, environmental monitoring, financial self-service and other industries.
