Product Details:
|
| Waterproof Rating: | Front IP65 | Led Panel: | 21.5" Industrial Android Tablet Pc |
|---|---|---|---|
| Resolution: | 1920 X 1080 | CPU: | ARM RK3288 Cortex-A17 1.8G |
| RAM: | 2GB/4GB/8GB ( Optional) | Harddisk: | EMMC 8G/16G ( Optional) |
| I/O Interface: | VGA/HD-MI/LAN/USB/RS232/RS485 | Touchscreen: | Capacitive Touch / Resistive |
| High Light: | Vesa Mounting industrial android tablet pc,4 USB industrial android tablet pc |
||
Feature for Industrial Android Tablet Pc
Industrial Android Tablet Pc can be widely used in the communications and control terminal of the telecommunications, electricity, multimedia, defense, medical, industrial automation equipment, manufacturing and other fields.
1,Intel® J1900 or 6th/8th generation Core i3/i5/i7 CPUs(optional)
2,1 SODIMM memory slot, supporting max 16GB
3,Full flat touch screen, IP65 front panel protection
4,Low power fanless
5,9 ~ 36V wide voltage input
| PPC-R215WAC | ||
| System | CPU | ARM RK3288 Cortex-A17 1.8 GHz |
| Memory | 2G DDR3 | |
| Storage | EMMC 8G(16G Optional) | |
| GPU | ARM Mali-T764 | |
| Lan | RTL 8211E 1000 Lan | |
| Audio | RTL ALC662 | |
| Operation System | Android 5.1 / 7. 1 /9.0 / Ubuntu 12.04 | |
| I / O | H-DMI | 1 x H-DMI |
| LAN | 1 x LAN | |
| USB | 4 x USB 2.0 | |
| COM | 2 x RS232 | |
| Audio | 1 x AUDIO | |
| Wireless Network | WiFi / Bluetooth ( 4G / Optional ) | |
| LCD Panel | Panel Size | 21.5" FHD Led |
| Resolution | 1920 x 1080 | |
| Aspect Ratio | 16:9 | |
| Display Brightness | 250 cd/m2 | |
| Contrast Ratio | 3000:1 | |
| Backlight Lifetime | 50000 Hr (min.) | |
| Viewing Angle | 89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D ) | |
| Touch screen | Touch Screen Type | Multi-Touch PCAP |
| Transmittance | >90% | |
| Response Time | <5ms | |
| Surface Hardness | ≥7H | |
| Supply Voltage | 5.0V DC | |
| Touch Life | ≧ 3000W | |
| Institutional | Material | High-strength Al-alloy, support IP65 |
| Color | Gray | |
| VESA Mounting | VESA: 100 x 100 mm | |
| Waterproof Rate | IP65 | |
| Product Dimension | 538 x 330 x 58 mm | |
| Cut-out Size | 520 x 312 mm | |
| Packing Size | 630 x 190 x 480 mm | |
| Gross Weight | 12 KG | |
| Power and Environment | Operating Temperature | -10~60°C |
| Storage Temperature | -20~80°C(-22~176°F) | |
| Relative Humidity | 5%~95%@40°C, non-condensing | |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A | |
| Working Voltage | DC 12V / optional(+9V~36V) | |
| Power Consumption | ≦20W | |
Advantages:
1. High quality Industrial Android Tablet Pc
2. Factory reasonable prices
3. Sensitive touch screen for Industrial Android Tablet Pc
4. CE/FCC/RoHS certificates passed
5. OEM/ODM service available for Industrial Android Tablet Pc
6. Professional and Effective Sales Team serves you .
FAQ
1)What is the MOQ?
A: MOQ is 1 pcs Industrial Android Tablet Pc
Sample is available for customer to check the quality before bulk order.
2)Do you accept OEM?
Yes,OEM and ODM is warmly welcomed.
It is our company’s strength,we can customize the LCD monitor so that can fully meet customers’ requirements.
3)What payment methods does your company accept?
T/T,Western Union,Paypal and secure payment on alibaba.
4)What’s the delivery time?
Sample:5-7 working days.bulk order 15-25 working days.
For customized products,delivery time is negotiable.
We will try our best to meet your delivery time.
5)What are the shipping ways?
We will ship the goods according to customer’s demand.
Normally by DHL,UPS,Fedex,TNT.
For bulk order,we also can ship by air,by sea.
