Product Details:
|
| CPU: | Intel Celeron 4305U Duad Core 2.1GHz | Memory: | DDR4L 2400MHz 4GB, Up To 32GB |
|---|---|---|---|
| Harddisk: | 32G SSD / (64G / 128G / 250G / 500G SSD) Optional | I/O Port: | VGA/HD-MI/LAN/USB/COM |
| Power Input: | DC 9V~36V | Operating System: | Windows 10, Linux, Ubuntu, Debian |
| Power Consumption: | ≦15W | Working Time: | 7*24h |
| High Light: | 4305U Rugged Embedded Computer,4 LAN Rugged Embedded Computer |
||
Feature
QYT's Rugged Embedded PC serves a broad spectrum of applications with designs focused on weathering harsh operational conditions. The durability of Rugged Embedded PC’s allow them to stand out as excellent candidates for GPS systems, 24 hour surveillance and IoT infrastructures. Resilient and reliable hardware equipped in this product lineup will provide the confidence one desires towards the longevity of their projects.
We offers many Fanless Embedded PCs that supply high performance and low power consumption. Their multiple I/Os along with a small footprint makes them an ideal computing solution for tight places. With less moving parts, maintenance as well as down time is lessened giving you the confidence of many years of service.
2. 1x DDR4L 2400MHz 4GB. Max up to 32GB
3. 4x GbE supporting Wake-on-LAN and PXE
4. 4*COM (RS232/R485 optional), 1*WiFi / Bluetooth/4G optional
5. Encryption onboard TPM2.0 module supported
6. DC9V～36V wide voltage input
7. -20°C ~70°C extended operating temperature
| EFIC-1000CC | ||
| System | CPU | Intel Celeron 4305U Duad Core 2.1GHz |
| L2 Cache | 2MB | |
| Chipsets | Intel 8th Skylake-U SOC | |
| Memory | DDR4L 2400MHz 4GB, Up to 32GB | |
| Harddisk | 1 x M.2 120G SSD / ( 250G / 500G SSD) Optional | |
| Graphics | Intel HD Graphics 610 | |
| Network | Intel® I211-AT GbE LAN | |
| Audio | Realtek ACL662 Audio controller | |
| Operation System | Windows 10, Linux, Ubuntu, Debian | |
| I / O | VGA | 1 x DP / 1 x HD-MI |
| LAN | 4 x LAN | |
| USB | 6 x USB2.0 / 4 x USB3.0 | |
| COM | 4 x RS232 | |
| Wireless Network | WiFi + Bluetooth ( Optional ) | |
| Other I/O Interface | 1 x Power Switch | |
| Institutional | Material | Aluminum Alloy Shell |
| Color | Grey / Silver / Black ( optional ) | |
| VESA Mounting | 208 x 100 mm / 208 x 60 mm | |
| Product Dimension | 220 x 145 x 62 mm | |
| Packing Size | 360 x 180 x 320 mm | |
| Gross Weight | 4.0 KG | |
| Power and Environment | Operating Temperature | -10~60°C |
| Storage Temperature | -20~80°C(-22~176°F) | |
| Relative Humidity | 5%~95%@40°C, non-condensing | |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A | |
| Working Voltage | DC 9V~36V | |
| Power Consumption | ≦15W | |
Advantages:
High performance to price ratio
All material good quality and good brand
ODM,OEM service
According to customer demand to find the most appropriate personalized hardware solutions for customer,
help you quickly launch your own embedded production
Industrial embedded PC computers with fanless operation avoid dust ingress whilst operating in industrial environments. The fanless operation on these embedded box pcs also increases shock resistance, reliability and durability, plus extended temperature ranges can be achieved. These industrial pcs are quieter than computers using fans and in industries such as food and pharma, the fanless operation avoids the circulation of dirt and pathogens around the environment.
