TPM2.0 AC240V Industrial Panel Mount Monitor 15.6" HDMI For Vision Detection

TPM2.0 AC240V Industrial Panel Mount Monitor 15.6" HDMI For Vision Detection
TPM2.0 AC240V Industrial Panel Mount Monitor 15.6" HDMI For Vision Detection TPM2.0 AC240V Industrial Panel Mount Monitor 15.6" HDMI For Vision Detection TPM2.0 AC240V Industrial Panel Mount Monitor 15.6" HDMI For Vision Detection

Large Image :  TPM2.0 AC240V Industrial Panel Mount Monitor 15.6" HDMI For Vision Detection

Product Details:
Place of Origin: Shenzhen, China
Brand Name: QYT
Certification: CE, FCC, RoHS, IP65
Model Number: PPC-5156WAR
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Foam + Carton
Delivery Time: 3-10 Business Days
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Set/Sets per Month

TPM2.0 AC240V Industrial Panel Mount Monitor 15.6" HDMI For Vision Detection

Description
IP Rating: Front IP65 Size: 15.6" FHD Led
Resolution: 1920x1080 CPU: Intel Core I5-8265U Quad Core 1.6GHz
RAM: 4GB, Up To 32GB Harddisk: 64G SSD / (128G / 250G / 500G SSD) Optional
I/O Interface: 2xLAN, 2xRS232/422/485, 1xH-DMI, 4xUSB Touchscreen: Resistive Touch / Capacitive
High Light:

TPM2.0 Industrial Panel Mount Monitor

,

AC240V Industrial Panel Mount Monitor

,

HDMI Waterproof Touch Screen Pc

15.6" I5 Industrial Touch Panel Pc For Vision Detection Ddr4 4g Ram Msata 64g Ssd

Feature
TPM 2.0:
The PC is with Built-in TPM2.0 for Hardware-based Security, ensuring secure data storage, as well as platform authentication and integrity auditing.

Wide Working Voltage:
This machine supports DC 9V~36V wide voltage input, with overcurrent, overvoltage and reverse connection protection


1. 15.6" TFT LED, resolution 1920x1080, 5 Wire Resistive touch


2. Intel Core i5-8265U Quad Core 1.6GHz

3. Ports: V1xHDMI, 4xUSB, 2xLAN, 2xCOM(RS232/422/485 freely switched)

4. Operating System: Windows 10 / Linux, Ubuntu, Debian

5. DC IN 9V-36V wide voltage

6. TPM2.0 for Hardware-based Security



PPC-5156WAR
System CPU Intel Core i5-8265U Quad Core 1.6GHz
L3 Cache 6MB
Memory DDR4L 2400MHz 4GB, Up to 32GB
Harddisk 1 x mSATA 64G SSD / (120G / 250G / 500G SSD) Optional
Graphics Intel HD Graphics 620
Network Intel® I211-AT GbE LAN
Audio Realtek ACL662 Audio controller
TPM TPM 2.0
Operation System Windows 10 / Linux, Ubuntu, Debian
I / O HDMI 1 x H-DMI
LAN 2 x LAN
USB 4 x USB 3.0
COM 2 x RS-232 / 422 / 485
Audio 1x Audio_out & Mic_in
Wireless Network WiFi / Bluetooth ( 4G / Optional )
Other I/O Interface 1 x Power Switch
LCD Panel Panel Size 15.6" FHD Led
Resolution 1920 x 1080
Aspect Ratio 16:9
Display Brightness 600 cd/m2
Contrast Ratio 1000:1
Backlight Lifetime 50000 Hr (min.)
Viewing Angle 89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
Touch screen Touch Screen Type 5 Wire Resistive touch
Transmittance >80%
Response Time <10ms
Surface Hardness ≥3H
Supply Voltage 5.0V DC
Touch Life ≧ 3500W
Institutional Material High-strength Al-alloy, support IP65
Color Silver / Black
VESA Mounting VESA: 100 x 100 mm
Waterproof Rate IP65
Product Dimension 400 x 250 x 60 mm
Cut-out Size 386 x 236 mm
Packing Size 460 x 180 x 400 mm
Gross Weight 7 KG
Power and Environment Operating Temperature -20~70°C
Storage Temperature -30~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC IN 9V~36V
Power Consumption ≦45W


TPM2.0 AC240V Industrial Panel Mount Monitor 15.6" HDMI For Vision Detection 0TPM2.0 AC240V Industrial Panel Mount Monitor 15.6" HDMI For Vision Detection 1



Product Advantage
1. Wide range: -20°C to 70°C working temperature range.

2. Industrial LCD panel is wide viewing angle with high nits and true color.

3. Motherboard is high performance and 7x24 continuous operation available.

4. Heat sink in back case great for heat dissipation and beautiful appearance.

5. Working voltage is wide range 9-36V, suitable for various industrial applications.

6. Symmetric design can be utillized in portrait mode with style.



Applications

Industrial automation

human Machine Interface

Marine control system

welding industry

supervisory control

numerical control device


Our Advantage
1. Experience
QYT has more than 10 years rich experience in Industrial Computer/monitor filed.

2. Wide products line
7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android pc...etc.which have excellent work performane.

3. Customization functions
It offers rich of interface to meet csutomers needs.

4. Widely useage environment
QYT computer/monitor which is widly used for kitchen,food industry, boat...etc



FAQ
1. Q: Are you a manufacturer or trading company?
A: We're a professional manufacturer with more than 10 years experience in industrial automation field.
2. Q: Do you provide ODM/OEM or customized service?
A: Yes,we support OEM&ODM service, let you get the products you want exactly.
3. Q: What certifications do you have?
A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.
4. Q: How long is the warranty?
A: Our factory promised warranty is 1 year.
5. Q:What is the lead time?
A: 3 business days for samples order, 15 business days for mass production.
6. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
