Product Details:
|
| Panel Size: | 23.8" LED | Resolution: | 1920 X 1080 |
|---|---|---|---|
| TPM: | TPM 2.0 | CPU: | Intel Core I7-8565U Quad Core 1.8GHz |
| Operation System: | Windows 10 / 11 / Linux, Ubuntu, Debian | Touch Screen Type: | Multi-Touch PCAP |
| Waterproof Rate: | IP65 /IP66 | Working Voltage: | DC IN 9V~36V |
| High Light: | i7-8565U industrial computer touch screen,PCAP industrial computer touch screen |
||
i7-8565U 24 inch industrial computer touch screen support Windows 11
1. Description:
The PPC-7024WCC is a compact touchscreen industrial computer with the Aintel Core i7-8565U Quad Core 1.8 ghz; 23.8" industrial LED displays and multi-touch glass sensors.". Designed with IP65 grade front panel and rear cover to prevent water and dust entry. The PPC-7024WCC panel industrial computer supports a variety of operating systems, including Linux and Windows, to ensure easy deployment of a variety of applications, which makes it ideal for use in automated factories.
|
PPC-7024WCC |
|
|
System |
|
|
CPU |
Intel Core i7-8565U Quad Core 1.8GHz |
|
L3 Cache |
8MB |
|
Memory |
DDR4L 2400MHz 4GB, Up to 64GB |
|
Harddisk |
1 x M.2 120G SSD / (250G / 500G / 1TB SSD) Optional |
|
Graphics |
Intel HD Graphics 620 |
|
Network |
Intel® I211-AT GbE LAN |
|
Audio |
Realtek ACL662 Audio controller |
|
TPM |
TPM 2.0 |
|
Operation System |
Windows 10 / 11 / Linux, Ubuntu, Debian |
|
I / O |
|
|
HDMI |
1 x H-DMI |
|
LAN |
2 x LAN |
|
USB |
3 x USB 3.0 / 1 x USB 2.0 |
|
COM |
2 x RS-232 / 422 / 485 |
|
Audio |
1x Audio_out & Mic_in |
|
Wireless Network |
WiFi / Bluetooth ( 4G / 5G Optional ) |
|
Other I/O Interface |
1 x Power Switch |
|
LCD Panel |
|
|
Panel Size |
23.8" FHD LED |
|
Resolution |
1920 x 1080 |
|
Aspect Ratio |
16:9 |
|
Display Brightness |
350 cd/m2 |
|
Contrast Ratio |
1000:1 |
|
Backlight Lifetime |
30000 Hr (min.) |
|
Viewing Angle |
89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D ) |
|
Touch screen |
|
|
Touch Screen Type |
Multi-Touch PCAP |
|
Transmittance |
>90% |
|
Response Time |
<5ms |
|
Surface Hardness |
≥7H |
|
Supply Voltage |
5.0V DC |
|
Touch Life |
≧ 3000W |
|
Institutional |
|
|
Material |
Stainless Steel Panel + Sheet Metal Painting Treated Back Shell |
|
Color |
Natural |
|
VESA Mounting |
VESA: 100 x 100 mm |
|
Waterproof Rate |
IP65 /IP66 |
|
Product Dimension |
585 x 354.5 x 65 mm |
|
Cut-out Size |
568 x 337 mm |
|
Packing Size |
730 x 200 x 530 mm |
|
Gross Weight |
18 KG |
|
Power and Environment |
|
|
Operating Temperature |
-20~70°C |
|
Storage Temperature |
-30~80°C(-22~176°F) |
|
Relative Humidity |
5%~95%@40°C, non-condensing |
|
Vibration Range |
5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
|
External Power Supply |
AC 100 - 240V~50/60Hz,1.5A |
|
Working Voltage |
DC IN 9V~36V |
|
Power Consumption |
≦60W |
