Product Details:
|
| CPU: | Intel Celeron J6412 Quad Core 2.0GHz | Memory: | 4GB, Up To 32GB |
|---|---|---|---|
| Harddisk: | 120G SSD / ( 250G / 500G SSD) Optional / 1 X 2.5" SATA | I/O Port: | 1*HDMI, 1*DP, 3*LAN, 6*USB, 2*COM |
| Power Input: | DC 9V～36V Voltage Input | Operating System: | Windows 10, Linux, Ubuntu, Debian |
| Power Consumption: | ≦15W | Working Time: | 7*24h |
| High Light: | Rugged Embedded Industrial Computer,J6412 Embedded Industrial Computer,Windows10 Rugged Embedded Computer |
||
Rugged Embedded Computer Features:
Fanless mini PCs are industrial grade computing solutions designed and built to withstand deployment in challenging environments to manage workloads for processing, storage, and connectivity. Fanless mini computers are great for deployment in challenging environments because they are passively cooled, utilize solid-state drives, and can be configured using wide temperature range components. All of these key features result in a ruggedized, fanless mini computing solution that has no moving parts and is resistant to dust, dirt, shocks, vibrations, and extreme temperatures.
| DIN-R2000CA | |
| System | |
| CPU | Intel® Elkhart Lake Celeron J16412 Quad-core 2.0GHz , TDP 10W |
| L2 Cache | 1.5MB |
| System Chipset | Integrated with Intel® SoC |
| Memory | DDR4L 3200MHz 4GB, MAX 32GB |
| Harddisk | 1 x M.2 120G SSD ( 250G / 500G / 2TB SSD) / 1 x 2.5" SATA |
| Graphics | Intel® UHD Graphics for 10th Gen Intel® Processors |
| Network | Intel® 225-V GbE LAN |
| Audio | Realtek ACL897 Audio controller |
| TPM | TPM 2.0 |
| Watchdog Timer | Software Programmable Supports 1~255 sec. System Reset |
| Operation System | Windows 10 / 11, Linux, Ubuntu |
| I / O | |
| VIDEO | 1 x DP / 1 x HD-MI |
| LAN | 3 x LAN 10/100/1000/2500 Mbps |
| USB | 2 x USB2.0 / 4 x USB3.0 |
| COM | 2 x RS-232 / 422 / 485 |
| DIO | DIO 8 Bits ( 4 In / 4 Out ) Optional |
| Audio | 1x Audio_out & Mic_in |
| Wireless Network | Optional (WiFi / Bluetooth / 4G / 5G ) |
| Power | |
| Power Adapter | 1 x Optional AC/DC 12V/4A , 48W |
| Power Mode | Support AT, ATX Mode |
| Power Input | 2-pin Terminal Block Connector with Power Input 9~36VDC |
| Power Protection | OVP (Over Voltage Protection) OCP (Over Current Protection) RPP(Reverse Polarity Protection) |
| Power Consumption | ≦20W |
| Physical | |
| Material | Aluminum Alloy Shell |
| Color | Grey / Silver / Black ( optional ) |
| Mounting | 210 x 30 mm / DIN-Rail |
| Product Dimension | 185 x 145 x 57 mm |
| Packing Size | 360 x 180 x 320 mm |
| Weight (Net) | 1.5 KG |
| Environment | |
| Operating Temperature | -20~70°C ( -4~158°F ) |
| Storage Temperature | -30~80°C (-22~176°F) |
| Relative Humidity | 5%~95%@40°C, non-condensing |
| Vibration Range | 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
| EMC | CE, FCC,ROHS |
Provide full control and communication functions:
