Product Details:
|
| LCD Size: | 17 Inch ( 5:4 ) | Resolution: | 1280 X 1024 |
|---|---|---|---|
| Name: | Waterproof Industrial All In One Pc | CPU: | I3-6100U |
| Memory: | DDR4L 2133MHz 4GB, 8G, 16G | Harddisk: | 1 X MSATA 128G SSD / (250G / 500G / 1TB SSD) Optional |
| Touch Type: | Capacitive Touch /resistance Touch | Power Consumption: | ≦30W |
| High Light: | Waterproof Industrial All In One PC FCC,Capacitive Touch Industrial All In One PC |
||
4g ram 128g ssd 1280 x 1024 17''capacitive touch waterproof industrial all in one pc
Product main features:
1. QYT provides a variety of full-plane different sizes from 8-24 inches, ultra-thin design.
2. The same size J1900/6th Core i3/i5/support customization.
3. The QYT fan industrial flat panel adopts a one-time die-casting aluminum body, conforms to EIA, and adopts modular design, wireless material design, dustproof, shockproof,
4. Adopt advanced embedded platform, high and low performance, high integration, rich I/O expansion functions
5. It adopts wide-voltage design, beautiful graphic design, the whole machine supports IP69K protection level, and supports remote power on and off.
| WPC-O017SCR | |
| System | |
| CPU | Intel® Bay Trail Core i3-6100U Dual Core 2.4GHz , TDP 15W |
| L2 Cache | 3.0MB |
| System Chipset | Integrated with Intel® SoC |
| Memory | DDR3L 1333MHz 4GB, Up to 8GB |
| Harddisk | 1 x mSATA 128G SSD / (250G / 500G / 1TB SSD) Optional |
| Graphics | Intel HD Graphics |
| Network | Intel 82583V 1000 Mbps port |
| Audio | Realtek ACL662 Audio controller |
| Watchdog Timer | Software Programmable Supports 1~255 sec. System Reset |
| Operation System | Windows 7 / 10 / 11, Linux, Ubuntu |
| I / O | |
| VIDEO | 1 x H-DMI ( Optional ) |
| LAN | 2 x LAN ( Optional ) |
| USB | 4 x USB ( Optional ) |
| COM | 2 x RS232 ( Optional ) |
| Wireless Network | WiFi + Bluetooth ( Optional ) |
| Other I/O Interface | 1 x Power Switch |
| Display | |
| LCD Size | 17" ( 5:4 ) |
| Resolution | 1280 x 1024 |
| Brightness (cd/m²) | 400 |
| Contrast Ratio | 1000:1 |
| Backlight MTBF | 50000 hrs |
| Viewing Angle | 80 / 80 / 70 / 70 (CR≥10) ( L / R / U / D ) |
| Touch screen | |
| Touch Type | 5 wire Resistive touch |
| Surface Hardness | ≥3H |
| Power | |
| Power Adapter | 1 x Optional AC/DC 12V/5A , 60W |
| Power Input | DC 12V~24V |
| Power Consumption | ≦30W |
| Physical | |
| Material | Inox / SUS304 / SUS316 |
| Mounting | Stand / Wall / VESA / Yoke |
| Dimension (W x H x D) | 392 x 325 x 56 mm |
| Packing Size | 500 x 180 x 450 mm |
| Weight (Net) | 7.8 kg |
| Environment | |
| Operating Temperature | -20~70°C ( -4~158°F ) |
| Storage Temperature | -30~80°C (-22~176°F) |
| Relative Humidity | 5%~95%@40°C, non-condensing |
| Vibration Protection | 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
| IP Level | IP67 / IP69K |
| EMC | CE, FCC,ROHS |
About us:
Industrial automation and control technologies are constantly changing the way production and manufacturing are done. Industrial automation increases workload, makes work more precise and accurate, improves product quality and durability, and most importantly gives factory owners much-needed breathing room. Currently, QYT's embedded industrial computers are the powerful driving force behind the innovation of industrial automation and the rapid development of various other industries. From software, hardware to system, QYT can complete and provide all the products you need for industrial automation needs. Our industrial PCs include industrial control panel PCs, CPU cards and motherboards available for industrial automation, industrial complete machines, embedded complete machines, and integrated hardware system solutions.
Why choose us?
(1) Direct manufacturer: QYT has been focusing on industrial computers for many years, with strong marketing and technical support.
(2) Customization: We have a professional team of electronic and structural engineers who can analyze and design products according to your requirements, and our QC will follow up to ensure that the products are of good quality.
(3) Competitive price, under the condition of ensuring good quality, we can provide the most reasonable price for cooperation
(4) certificate. All of our products have obtained CE, RoHS and other certifications.
(5) After-sales service;
Warranty period: one year for the whole machine, our engineers will provide 24-hour service
