Product Details:
|
| CPU: | Intel Core I5-8265U Quad Core 1.6GHz | Memory: | 4GB/8GB/16GB |
|---|---|---|---|
| Storage: | 32G SSD/64G SSD/128G SSD | System: | Windows8 / 10, Linux, Unix, QNX |
| Material: | Aluminum Alloy Shell | External Power Supply: | AC 100 - 240V~50/60Hz,1.5A |
| TPM: | TPM2.0 | I/O: | 1xHDMI,2xLAN,4xUSB3.0,2xRS232/422/485 |
| Working Voltage: | DC IN 9V~36V | Power Consumption: | ≦25W |
| High Light: | Sandblasting Fanless Box Pc,25W Fanless Box Pc,Hard Anodic Oxidation Fanless Mini Pc |
||
25w I3 I5 I7 Fanless Box Pc Ac 100 - 240v A Heat Sink
FEATURES
1. The aluminum alloy structure, hard anodic oxidation treatment of sandblasting, resistance to scratch
2. CPU: Intel Core i5-8265U Quad Core 1.6GHz, Fanless configuration
3. Two gigabit front-end ports, two serial RS232/422/485, 8 kv static and 600w TVS surge protection
4. The onboard TPM2.0 module provides maximum security hardware
5. Wide voltage DC 9 v ~ 36 v, over-current, over-voltage and reverse connect protection
Specification
| EFIC-50005A | ||
| System | CPU | Intel Core i5-8265U Quad Core 1.6GHz |
| L2 Cache | 6MB | |
| Chipsets | Intel Whiskey Lake SOC | |
| Memory | DDR4L 2400MHz 4GB, Up to 32GB | |
| Harddisk | 1 x mSATA 64G SSD / (120G / 250G / 500G SSD) Optional | |
| Graphics | Intel HD Graphics 620 | |
| Network | Intel® I211-AT GbE LAN | |
| Audio | Realtek ACL662 Audio controller | |
| TPM | TPM 2.0 | |
| Operation System | Windows 10 / Linux, Ubuntu, Debian | |
| I / O | Display | 1 x H-DMI |
| LAN | 2 x LAN | |
| USB | 4 x USB3.0 | |
| COM | 2 x RS-232 / 422 / 485 | |
| Audio | 1x Audio_out & Mic_in | |
| Wireless Network | WiFi + Bluetooth ( Optional ) | |
| Other I/O Interface | 1 x Power Switch | |
| Institutional | Material | Aluminum Alloy Shell |
| Color | Gray / Silver / Black ( optional ) | |
| Fixed size | 272 x 90 mm / 272 x 60 mm | |
| Product Dimension | 258 x 158 x 33 mm | |
| Packing Size | 360 x 180 x 320 mm | |
| Gross Weight | 4.0 KG | |
| Power and Environment | Operating Temperature | -20~70°C |
| Storage Temperature | -20~80°C(-22~176°F) | |
| Relative Humidity | 5%~95%@40°C, non-condensing | |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A | |
| Working Voltage | DC IN 9V~36V | |
| Power Consumption | ≦25W | |
FAQ
1. Q: Are you a manufacturer or trading company?
A: We're a professional manufacturer with more than 10 years experience in industrial automation field.
2. Q: Do you provide ODM/OEM or customized service?
A: Yes,we support OEM&ODM service, let you get the products you want exactly.
3. Q: What certifications do you have?
A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.
4. Q: How long is the warranty?
A: Our factory promised warranty is 1 year.
5. Q:What is the lead time?
A: 3 business days for samples order, 15 business days for mass production.
6. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
Our Advantage
1. Experience
QYT has more than 10 years rich experience in Industrial Computer/monitor filed.
2. Wide products line
7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android pc...etc.which have excellent work performane.
3. Customization functions
It offers rich of interface to meet csutomers needs.
4.Widely useage environment
QYT computer/monitor which is widly used for kitchen,food industry, boat...etc
