Product Details:
|
| IP Rating: | Front IP65 | Led Panel: | 21.5" FHD LED |
|---|---|---|---|
| Resolution: | 1920 X 1080 | CPU: | Intel Core I7-8565U Quad Core 1.8GHz |
| Memory: | DDR4L 2400MHz 4GB, Up To 64GB | HDD: | M.2 120G SSD / (250G / 500G / 1TB SSD) Optional |
| I/O Interface: | 1xHD-MI, 4xUSB, 2xLAN, 2xCOM(RS232/422/485 Freely Switched) | Touchscreen: | Resistive / Capacitive Touch |
| High Light: | I7-8565U ip65 Touch Screen Pc,Fanless ip65 Touch Screen Pc,FHD LED fanless industrial computer |
||
Manufacturing areas are often times very harsh environments, and one of the most invasive sources of contamination in these settings is dust and other airborne particulates such as carbon powder, metallic debris, and oils. When this contamination enters a computer, it coats components and reduces performance, shortens the product life, and can cause outright failure. QYT fanless panel PCs include unique thermal designs that allow for fanless operation without ventilation holes. Fanless panel PCs are protected from dust contamination, as they do not draw dust into their enclosures.
Application:
It is ideal for applications such as law enforcement, pharmaceutical, utiilities, government, security, defense, public sector, industrial, warehouse, logistics, hospitality, retail management and some other outdoor place.
| PPC-7215WAR | ||
| System | CPU | Intel Core i7-8565U Quad Core 1.8GHz |
| L3 Cache | 8MB | |
| Memory | DDR4L 2400MHz 4GB, Up to 64GB | |
| Harddisk | 1 x M.2 120G SSD / (250G / 500G / 1TB SSD) Optional | |
| Graphics | Intel HD Graphics 620 | |
| Network | Intel® I211-AT GbE LAN | |
| Audio | Realtek ACL662 Audio controller | |
| TPM | TPM 2.0 | |
| Operation System | Windows 10 / 11 / Linux, Ubuntu, Debian | |
| I / O | Video | 1 x H-DMI |
| LAN | 2 x LAN | |
| USB | 3 x USB 3.0 / 1 x USB 2.0 | |
| COM | 2 x RS-232 / 422 / 485 | |
| Audio | 1x Audio_out & Mic_in | |
| Wireless Network | WiFi / Bluetooth ( 4G / 5G Optional ) | |
| Other I/O Interface | 1 x Power Switch | |
| LCD Panel | Panel Size | 21.5" FHD LED |
| Resolution | 1920 x 1080 | |
| Aspect Ratio | 16:9 | |
| Display Brightness | 400 cd/m2 | |
| Contrast Ratio | 1000:1 | |
| Backlight Lifetime | 50000 Hr (min.) | |
| Viewing Angle | 89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D ) | |
| Touch screen | Touch Screen Type | 5 Wire Resistive touch |
| Transmittance | >80% | |
| Response Time | <10ms | |
| Surface Hardness | ≥3H | |
| Supply Voltage | 5.0V DC | |
| Touch Life | ≧ 3500W | |
| Institutional | Material | High-strength Al-alloy |
| Color | Gray | |
| VESA Mounting | VESA: 100 x 100 mm | |
| Waterproof Rate | IP65 / IP66 | |
| Product Dimension | 538 x 330 x 62 mm | |
| Cut-out Size | 520 x 312 mm | |
| Packing Size | 630 x 190 x 480 mm | |
| Gross Weight | 12 KG | |
| Power and Environment | Operating Temperature | -20~70°C |
| Storage Temperature | -30~80°C(-22~176°F) | |
| Relative Humidity | 5%~95%@40°C, non-condensing | |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A | |
| Working Voltage | DC IN 9V~36V | |
| Power Consumption | ≦45W | |
Applications
Industrial automation
human Machine Interface
Marine control system
welding industry
supervisory control
numerical control device
