Product Details:
|
| Product Name: | 19inch Industrial HMI PC | IP Rating: | Front IP65 Industrial HMI PC |
|---|---|---|---|
| Led Panel: | 19'' Led | Resolution: | 1280 X 1024 |
| CPU: | Intel Core I7-8565U Quad Core 1.8GHz | RAM: | DDR4L 2400MHz 4GB, Up To 64GB |
| Harddisk: | 1 X M.2 120G SSD / (250G / 500G / 1TB SSD) Optional | I/O Port: | 1 X HD-MI, 2x LAN, 2 X COM, 4 X USB Optional |
| High Light: | Rugged 19inch Industrial HMI PC,Front IP65 WiFi HMI Panel PC,19'' Led HMI Panel PC |
||
Capacitive Resistive touch 19inch industrial HMI PC with 4G 5G WiFi
1. 19 Inch Industrial HMI PC of Product Highlights:
• aluminum housing, IP65 waterproof Industrial HMI PC
• 19" Industrial HMI PC, resolution 1280 x 1024, multi-point capacitive touch screen
• 8th Gen i7/i5/i3/ processors
• 2 LAN ports supporting high-speed EtherCAT and jumbo frame capabilities
• 2×RS-232 / 422 / 485 ports with surge protection, RS485 supports automatic flow direction control
• DC9~36V wide voltage input, support reverse polarity protection, overvoltage protection, overcurrent protection
• I/O Interface: HDMI/LAN /USB / COM
|
PPC-7019SAC |
|
|
System |
|
|
CPU |
Intel Core i7-8565U Quad Core 1.8GHz |
|
L3 Cache |
8MB |
|
Memory |
DDR4L 2400MHz 4GB, Up to 64GB |
|
Harddisk |
1 x M.2 120G SSD / (250G / 500G / 1TB SSD) Optional |
|
Graphics |
Intel HD Graphics 620 |
|
Network |
Intel® I211-AT GbE LAN |
|
Audio |
Realtek ACL662 Audio controller |
|
TPM |
TPM 2.0 |
|
Operation System |
Windows 10 / 11 / Linux, Ubuntu, Debian |
|
I / O |
|
|
Video |
1 x H-DMI |
|
LAN |
2 x LAN |
|
USB |
3 x USB 3.0 / 1 x USB 2.0 |
|
COM |
2 x RS-232 / 422 / 485 |
|
Audio |
1x Audio_out & Mic_in |
|
Wireless Network |
WiFi / Bluetooth ( 4G / 5G Optional ) |
|
Other I/O Interface |
1 x Power Switch |
|
LCD Panel |
|
|
Panel Size |
19" LED |
|
Resolution |
1280 x 1024 |
|
Aspect Ratio |
5:4 |
|
Display Brightness |
450 cd/m2 |
|
Contrast Ratio |
1000:1 |
|
Backlight Lifetime |
50000 Hr (min.) |
|
Viewing Angle |
85 / 85 / 80 / 80 (CR≥10) ( L / R / U / D ) |
|
Touch screen |
|
|
Touch Screen Type |
Multi-Touch PCAP |
|
Transmittance |
>90% |
|
Response Time |
<5ms |
|
Surface Hardness |
≥7H |
|
Supply Voltage |
5.0V DC |
|
Touch Life |
≧ 3000W |
|
Institutional |
|
|
Material |
High-strength Al-alloy |
|
Color |
Gray |
|
VESA Mounting |
VESA: 100 x 100 mm |
|
Waterproof Rate |
IP65 / IP66 |
|
Product Dimension |
438 x 362 x 62 mm |
|
Cut-out Size |
420 x 345 mm |
|
Packing Size |
500 x 180 x 450 mm |
|
Gross Weight |
8 KG |
|
Power and Environment |
|
|
Operating Temperature |
-20~70°C |
|
Storage Temperature |
-30~80°C(-22~176°F) |
|
Relative Humidity |
5%~95%@40°C, non-condensing |
|
Vibration Range |
5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
|
External Power Supply |
AC 100 - 240V~50/60Hz,1.5A |
|
Working Voltage |
DC IN 9V~36V |
|
Power Consumption |
≦45W |
2. Why choose us?
Fast delivery capability for Industrial HMI PC
Rich project experience
Products created by private models for Industrial HMI PC
Strong R&D and independent design capabilities
Professional pre-sales and after-sales service team.
3. OEM/ODM Service
*Professional R&D team, pre-sales and after-sales service,10 years OEM & ODM Service,Provide you with professional solutions.
*Our goal is " Customer First, Service First". We are committed to providing quality products,excellent services,
*competitive prices, quick responses and prompt delivery. Therefore, we keep long-term cooperation with our customers.
