15" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC

Certification
China QYT industry Co.,Ltd certification
China QYT industry Co.,Ltd certification
Customer Reviews
I use these industrial embedded box pc for machine control, they work great, and the fanless design is a huge plus in an environment where small metal particles are everywhere. The Wi-Fi reception is excellent, continuous work, wide voltage DC 9V~36V and reverse connection protection, as in description, everything works perfect, good communication.

—— Lacroix Philippe

Great industrial touch panel pc easy to work with and well constructed, fast delivery, with windows 10, TPM2.0 Provide a secure encryption key. our equipment needed multiple USB inputs . And if I need to ever control any external devices by RS232 or RS422 or RS485 ports opens up so many possibilities. nice product, I highly recommend it.

—— Roy Smith

I'm Online Chat Now

15" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC

15" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC
15" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC 15" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC 15" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC

Large Image :  15" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC

Product Details:
Place of Origin: Shenzhen, China
Brand Name: QYT
Certification: CE, FCC, RoHS, IP65
Model Number: PPC-3015SAC
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Foam + Carton
Delivery Time: 3-10 Business Days
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Set/Sets per Month

15" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC

Description
Waterproof Rating: Front IP65 Led Panel: 15" LED
Resolution: 1024 X 768 CPU: Intel Core I3-8145U Dual Core 2.1GHz
RAM: DDR4L 2400MHz 4GB, Up To 32GB HDD: 1 X M.2 120G SSD / (250G / 500G / 1TB SSD) Optional
I/O Ports: 1xHDMI, 4xUSB, 2xLAN, 2xCOM Touchscreen: Capacitive Touch / Resistive Touch
High Light:

Linux Capacitive Multi Touch Panel

,

Fanless Capacitive Multi Touch Panel

,

Fanless Industrial AIO PC

15" 8th Gen I3 Linux Capacitive Multi Touch Panel Industrial AIO PC Fanless Computer

Feature

Industrial Touch Panel PC:

Unlike traditional enterprise all-in-one PCs, industrial panel PCs are engineered designed to withstand the harshest environments. VESA mountable and touchscreen capable, our panel PCs are ready to be embedded and integrated into virtually any industrial environment, even outdoors. Fanless cooling helps protect internal components from dust and debris that typically damages computers in industrial areas. QYT's Industrial Panel PCs are also customizable with multiple legacy ports and expansion slots to ensure their versatility and ability to be adapted to any job.



Industrial touch panel pc features:

1. 15" TFT LED, resolution 1024 x 768, capacitive touch
2. Intel Core i3-8145U Dual Core 2.1GHz
3. 4GB RAM, 128G SSD
4. Ports: 1xHDMI, 4xUSB, 2xLAN, 2xCOM(RS232/422/485 freely switched)
5. 1000nits high brightness
5. Operating System: Windows 10 / Linux, Ubuntu, Debian
6. DC9V~36V Input
7. TPM2.0, Hardware Encryption
8. -20°C~70°C Operating Temperature;



PPC-3015SAC
System
CPU Intel Core i3-8145U Dual Core 2.1GHz
L3 Cache 4MB
Memory DDR4L 2400MHz 4GB, Up to 64GB
Harddisk 1 x M.2 120G SSD / (250G / 500G / 1TB SSD) Optional
Graphics Intel HD Graphics 620
Network Intel® I211-AT GbE LAN
Audio Realtek ACL662 Audio controller
TPM TPM 2.0
Operation System Windows 10 / 11 / Linux, Ubuntu, Debian
I / O
Video 1 x H-DMI
LAN 2 x LAN
USB 3 x USB 3.0 / 1 x USB 2.0
COM 2 x RS-232 / 422 / 485
Audio 1x Audio_out & Mic_in
Wireless Network WiFi / Bluetooth ( 4G / 5G Optional )
Other I/O Interface 1 x Power Switch
LCD Panel
Panel Size 15" LED
Resolution 1024 x 768
Aspect Ratio 4:3
Display Brightness 350 cd/m2
Contrast Ratio 1000:1
Backlight Lifetime 50000 Hr (min.)
Viewing Angle 89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
Touch screen
Touch Screen Type Multi-Touch PCAP
Transmittance >90%
Response Time <5ms
Surface Hardness ≥7H
Supply Voltage 5.0V DC
Touch Life ≧ 3000W
Institutional
Material High-strength Al-alloy
Color Gray
VESA Mounting VESA: 100 x 100 mm
Waterproof Rate IP65 / IP66
Product Dimension 361 x 285 x 62 mm
Cut-out Size 347 x 271 mm
Packing Size 460 x 180 x 400 mm
Gross Weight 7 KG
Power and Environment
Operating Temperature -20~70°C
Storage Temperature -30~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC IN 9V~36V
Power Consumption ≦35W


15" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC 015" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC 115" 8th Gen I3 Linux Capacitive Multi Touch Panel Fanless Industrial AIO PC 2



Industrial Panel PC are industrial control computers specially designed for industrial use.

Their basic performance and compatibility are similar to those of commercial computers.



But Industrial Panel PC focus more on stability in different environments, such as beverage production line control, automotive Production line control, etc.

It requires stability in harsh environments, such as dust-proof, waterproof, anti-static, etc.



Industrial Panel PCs do not require the current highest performance, but only meet the requirements of the system, and must meet the reliability and stability requirements in the industrial environment. Otherwise, if the production line encounters a computer crash, it may cause serious losses. So the standard values required by Panel PCs must meet strict specifications and scalability.



Advantages:

1. High quality products

2. Factory reasonable prices

3. Sensitive touch screen

4. CE/FCC/RoHS certificates passed

5. OEM/ODM service available

6. Professional and Effective Sales Team serves you.
