15'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz

Certification
China QYT industry Co.,Ltd certification
China QYT industry Co.,Ltd certification
Customer Reviews
I use these industrial embedded box pc for machine control, they work great, and the fanless design is a huge plus in an environment where small metal particles are everywhere. The Wi-Fi reception is excellent, continuous work, wide voltage DC 9V~36V and reverse connection protection, as in description, everything works perfect, good communication.

—— Lacroix Philippe

Great industrial touch panel pc easy to work with and well constructed, fast delivery, with windows 10, TPM2.0 Provide a secure encryption key. our equipment needed multiple USB inputs . And if I need to ever control any external devices by RS232 or RS422 or RS485 ports opens up so many possibilities. nice product, I highly recommend it.

—— Roy Smith

I'm Online Chat Now

15'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz

15'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz
15'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz 15'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz 15'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz

Large Image :  15'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz

Product Details:
Place of Origin: Shenzhen, China
Brand Name: QYT
Certification: CE, FCC, RoHS, IP65
Model Number: PPC-3015SAC
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Foam + Carton
Delivery Time: 3-10 Business Days
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Set/Sets per Month

15'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz

Description
Type: Panel Pc 15 Capacitive Touch Screen Intel Core I3-8145U Dual Core 2.1GHz Led Panel: 15" LED
Resolution: 1024 X 768 CPU: Intel Core I3-8145U Dual Core 2.1GHz
RAM: DDR4L 2400MHz 4GB, Up To 32GB HDD: 1 X M.2 120G SSD / (250G / 500G / 1TB SSD) Optional
I/O Ports: 1xHDMI, 4xUSB, 2xLAN, 2xCOM TPM: TPM 2.0
High Light:

15'' Capacitive Touch Panel PC

,

TPM 2.0 Capacitive Touch Panel PC

,

Hardware Encryption capacitive touch screen pc

Panel Pc 15 Capacitive Touch Screen Intel Core I3-8145U Dual Core 2.1GHz



Manufacturing areas are often times very harsh environments, and one of the most invasive sources of contamination in these settings is dust and other airborne particulates such as carbon powder, metallic debris, and oils. When this contamination enters a computer, it coats components and reduces performance, shortens the product life, and can cause outright failure. QYT fanless panel PCs include unique thermal designs that allow for fanless operation without ventilation holes. Fanless panel PCs are protected from dust contamination, as they do not draw dust into their enclosures.



Industrial touch panel pc features:

1. 15" TFT LED, resolution 1024 x 768, capacitive touch
2. Intel Core i3-8145U Dual Core 2.1GHz
3. 4GB RAM, 128G SSD
4. Ports: 1xHDMI, 4xUSB, 2xLAN, 2xCOM(RS232/422/485 freely switched)
5. 1000nits high brightness
5. Operating System: Windows 10 / Linux, Ubuntu, Debian
6. DC9V~36V Input
7. TPM2.0, Hardware Encryption
8. -20°C~70°C Operating Temperature;



PPC-3015SAC
System
CPU Intel Core i3-8145U Dual Core 2.1GHz
L3 Cache 4MB
Memory DDR4L 2400MHz 4GB, Up to 64GB
Harddisk 1 x M.2 120G SSD / (250G / 500G / 1TB SSD) Optional
Graphics Intel HD Graphics 620
Network Intel® I211-AT GbE LAN
Audio Realtek ACL662 Audio controller
TPM TPM 2.0
Operation System Windows 10 / 11 / Linux, Ubuntu, Debian
I / O
Video 1 x H-DMI
LAN 2 x LAN
USB 3 x USB 3.0 / 1 x USB 2.0
COM 2 x RS-232 / 422 / 485
Audio 1x Audio_out & Mic_in
Wireless Network WiFi / Bluetooth ( 4G / 5G Optional )
Other I/O Interface 1 x Power Switch
LCD Panel
Panel Size 15" LED
Resolution 1024 x 768
Aspect Ratio 4:3
Display Brightness 350 cd/m2
Contrast Ratio 1000:1
Backlight Lifetime 50000 Hr (min.)
Viewing Angle 89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
Touch screen
Touch Screen Type Multi-Touch PCAP
Transmittance >90%
Response Time <5ms
Surface Hardness ≥7H
Supply Voltage 5.0V DC
Touch Life ≧ 3000W
Institutional
Material High-strength Al-alloy
Color Gray
VESA Mounting VESA: 100 x 100 mm
Waterproof Rate IP65 / IP66
Product Dimension 361 x 285 x 62 mm
Cut-out Size 347 x 271 mm
Packing Size 460 x 180 x 400 mm
Gross Weight 7 KG
Power and Environment
Operating Temperature -20~70°C
Storage Temperature -30~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC IN 9V~36V
Power Consumption ≦35W


15'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz 015'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz 115'' Capacitive Touch Panel PC Intel Core I3-8145U Dual Core 2.1GHz 2



Panel Pc 15 Capacitive Touch Screen

Industrial-grade Panel PCs come with a range of housing to meet every industrial condition, not to mention low-power consumption or high-performance processors to suit different applications. From HMI terminals in Smart Factories and Buildings, or as POS/POI in the transportation and retail sectors, these Panel PCs can handle it all.

Panel mount panel PC is perfect for space considerations and support panel, front mount, and VESA mounting for different applications.
