Product Details:
|
| Type: | Industrial Pc I7 Intel Core I7-8565U Quad Core 1.8GHz 17.3" Widescreen 1920 X 1080 | Led Panel: | 17.3" LED |
|---|---|---|---|
| Resolution: | 1920 X 1080 | CPU: | Intel Core I7-8565U Quad Core 1.8GHz |
| Memory: | 4GB, Up To 32GB | HDD: | 1 X M.2 120G SSD / (250G / 500G / 1TB SSD) Optional |
| I/O Interface: | 1xHDMI, 4xUSB, 2xLAN, 2xCOM | Working Voltage: | DC IN 9V~36V |
| High Light: | capacitive touch Industrial Touch Panel PC,I7-8565U Industrial Touch Panel PC |
||
Industrial pc i7 Intel Core i7-8565U Quad Core 1.8GHz 17.3" widescreen 1920 x 1080
Industrial Panel PCs Built for Long-Term Operation in the Most Demanding Work EnvironmentsBuilt to reliably withstand the rigors of long term operation in even the most extreme work environments, Teguar’s industrial touchscreen panel PCs easily handle vibration, moisture, water, shock, and dust. Thanks to a fanless cooling system, these panel mountable pcs deliver reliable and quiet productivity 24/7. The interior of each industrial touchscreen PC is comprised of industrial-grade components designed to stand the test of time operating in harsh environments. The touchscreens and front bezels are IP65 waterproof rated and carry a NEMA 4X protection rating.
| PPC-7173WAC | |
| System | |
| CPU | Intel Core i7-8565U Quad Core 1.8GHz |
| L3 Cache | 8MB |
| Memory | DDR4L 2400MHz 4GB, Up to 64GB |
| Harddisk | 1 x M.2 120G SSD / (250G / 500G / 1TB SSD) Optional |
| Graphics | Intel HD Graphics 620 |
| Network | Intel® I211-AT GbE LAN |
| Audio | Realtek ACL662 Audio controller |
| TPM | TPM 2.0 |
| Operation System | Windows 10 / 11 / Linux, Ubuntu, Debian |
| I / O | |
| Video | 1 x H-DMI |
| LAN | 2 x LAN |
| USB | 3 x USB 3.0 / 1 x USB 2.0 |
| COM | 2 x RS-232 / 422 / 485 |
| Audio | 1x Audio_out & Mic_in |
| Wireless Network | WiFi / Bluetooth ( 4G / 5G Optional ) |
| Other I/O Interface | 1 x Power Switch |
| LCD Panel | |
| Panel Size | 17.3" LED |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Display Brightness | 400 cd/m2 |
| Contrast Ratio | 600:1 |
| Backlight Lifetime | 50000 Hr (min.) |
| Viewing Angle | 80 / 80 / 60 / 80 (CR≥10) ( L / R / U / D ) |
| Touch screen | |
| Touch Screen Type | Multi-Touch PCAP |
| Transmittance | >90% |
| Response Time | <5ms |
| Surface Hardness | ≥7H |
| Supply Voltage | 5.0V DC |
| Touch Life | ≧ 3000W |
| Institutional | |
| Material | High-strength Al-alloy |
| Color | Gray |
| VESA Mounting | VESA: 100 x 100 mm |
| Waterproof Rate | IP65 / IP66 |
| Product Dimension | 441 x 274 x 62 mm |
| Cut-out Size | 427 x 260 mm |
| Packing Size | 500 x 180 x 450 mm |
| Gross Weight | 8 KG |
| Power and Environment | |
| Operating Temperature | -20~70°C |
| Storage Temperature | -30~80°C(-22~176°F) |
| Relative Humidity | 5%~95%@40°C, non-condensing |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A |
| Working Voltage | DC IN 9V~36V |
| Power Consumption | ≦45W |
Industrial touchscreen computers designed and manufactured by QYT survive the toughest and harshest environments plus industrial applications. Our rugged computers provide the highest level of long-term reliability in 24/7 operation. These industrial touchscreen PCs are designed and built in house with a focus on reliability as well as quality. Our industrial computer portfolio includes: Industrial Panel PC, Waterproof Panel PC, Embedded Fanless Industrial Computer, Device Control Panel, Industrial Touch Monitor.
