Product Details:
|
| IP Rating: | IP66 / IP69K | Led Panel: | 12.1" Led |
|---|---|---|---|
| Resolution: | 1280 X 800 | CPU: | Intel Core I5-6200U Dual Core 2.5GHz |
| Memory: | 4GB, Up To 16GB | HDD: | 128G SSD / (250G / 500G / 1TB SSD) Optional |
| I/O Interface: | VGA/HD-MI/LAN/USB/COM | Touchscreen: | Capacitive Touch / Resistive |
| High Light: | 12.1" TFT Waterproof Touch Screen PC,1280*800 Waterproof Touch Screen PC,Fanless Waterproof Touch Screen Computer |
||
About US
A Waterproof Touch Screen Industrial Panel PC from QYT combines advanced computing power with a range of hardened displays. Modular solutions enable easy customization and simplified upgrading while reducing maintenance costs. Our PPC line of IP65 Touch Screen panels with ingress protection and rugged plug and play attachable PCs, make for a modular and extremely economical solution. You choose the screen size and PC with the power and performance you need. QYT All-in-One Waterproof Touch Screen Panel PCs are available in various screen sizes and have a compact, fully integrated enclosure. Industrial touchscreen solutions from QYT provide a rugged solution for human/machine interface (HMI), in-vehicle use, inventory management, point of use, kiosk or industrial control applications.
Waterproof Touch Screen PC Feature
From IP66 to IP68/IP69K (on all sides)
As rugged as it gets – QYT waterproof touchscreen PCs are certified up to protection class IP68/IP69K and can fully withstand the most extreme conditions, including high-pressure cleaning from all sides with 80+ degree hot water.
| WPC-P012WAC | |
| System | |
| CPU | Intel® Bay Trail Core i5-6200U Dual Core 2.5GHz , TDP 15W |
| L2 Cache | 3.0MB |
| System Chipset | Integrated with Intel® SoC |
| Memory | DDR4L 2133MHz 4GB, Up to 16GB |
| Harddisk | 1 x mSATA 128G SSD / (250G / 500G / 1TB SSD) Optional |
| Graphics | Intel HD Graphics 520 |
| Network | Intel® I211-AT GbE LAN |
| Audio | Realtek ACL662 Audio controller |
| Watchdog Timer | Software Programmable Supports 1~255 sec. System Reset |
| Operation System | Windows 7 / 10 / 11, Linux, Ubuntu |
| I / O | |
| VIDEO | 1 x H-DMI ( Optional ) |
| LAN | 2 x LAN ( Optional ) |
| USB | 4 x USB ( Optional ) |
| COM | 2 x RS232 ( Optional ) |
| Wireless Network | WiFi + Bluetooth ( Optional ) |
| Other I/O Interface | 1 x Power Switch |
| Display | |
| LCD Size | 12.1" ( 19:10 ) |
| Resolution | 1280 x 800 |
| Brightness (cd/m²) | 400 |
| Contrast Ratio | 1000:1 |
| Backlight MTBF | 50000 hrs |
| Viewing Angle | 88 / 88 / 88 / 88 (CR≥10) ( L / R / U / D ) |
| Touch screen | |
| Touch Type | Multi-Touch PCAP |
| Surface Hardness | ≥7H |
| Power | |
| Power Adapter | 1 x Optional AC/DC 12V/5A , 60W |
| Power Input | DC 12V~24V |
| Power Consumption | ≦30W |
| Physical | |
| Material | Aluminum Alloy Shell |
| Mounting | Stand / Wall / VESA / Yoke |
| Dimension (W x H x D) | 312 x 214 x 40 mm |
| Packing Size | 450 x 170 x 350 mm |
| Weight (Net) | 2.8 kg |
| Environment | |
| Operating Temperature | -20~70°C ( -4~158°F ) |
| Storage Temperature | -30~80°C (-22~176°F) |
| Relative Humidity | 5%~95%@40°C, non-condensing |
| Vibration Protection | 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
| IP Level | IP66 / IP69K |
| EMC | CE, FCC,ROHS |
Product Advantage
1. Robust aluminum alloy/stainless steel enclosure, sealed I/O from particles, water, and corrosive agents
2. Full IP66/69K sealed to providing 360 degree protection
3. Windows-based with integrated CPU, RAM, storage, USB, RS232, and LAN ports
4. Flexible, reliable, and rugged for open platform HMI/SCADA
5. Provides improved power efficiency and reduced consumption
6. CE, FCC, RoHS, IP69K Compliance
