Product Details:
|
IP Grade: | IP67 / IP69K | Material : | Aluminum Alloy Shell |
---|---|---|---|
Name: | 21.5'' Waterproof Industrial Panel Pc | Product Resolution: | 1920 X 1080 ( FHD ) |
I/O Ports: | HD-MI/LAN/USB/COM | Memory: | DDR3L 1333MHz 4GB |
Harddisk: | 128 GB | Operation System: | Windows 10 ,Linux, Ubuntu |
High Light: | 21.5" Industrial Waterproof Panel PC,Resistive Touch Industrial Waterproof Panel PC |
21.5" Industrial waterproof PC I3 Resistive Touch Screen windows / Linux
Product main features:
1. QYT provides a variety of full-plane different sizes from 8-24 inches, ultra-thin design.
2. The same size J1900/6th Core i3/i5/support customization.
3. The QYT fan industrial flat panel adopts a one-time die-casting aluminum body, conforms to EIA, and adopts modular design, wireless material design, dustproof, shockproof,
4. Adopt advanced embedded platform, high and low performance, high integration, rich I/O expansion functions
5. It adopts wide-voltage design, beautiful graphic design, the whole machine supports IP69K protection level, and supports remote power on and off.
WPC-O215WAR |
|
System |
|
CPU |
Intel Core i3-6100U Dual Core 2.4GHz |
L2 Cache |
3MB |
System Chipset |
Intel 6th Skylake-U SOC |
Memory |
DDR4L 2133MHz 4GB, Up to 16GB |
Harddisk |
1 x mSATA 128G SSD / ( 256G / 500G / ITB SSD) optional |
Graphics |
Intel HD Graphics |
Network |
Intel® I211-AT GbE LAN |
Audio |
Realtek ACL662 Audio controller |
Watchdog Timer |
Software Programmable Supports 1~255 sec. System Reset |
Operation System |
Windows 7 / 8 / 10 ,Linux, Ubuntu |
I / O |
|
VIDEO |
1 x HD-MI ( Optional ) |
LAN |
2 x LAN ( Optional ) |
USB |
4 x USB2.0 ( Optional ) |
COM |
2 x RS232 ( Optional ) |
Wireless Network |
WiFi + Bluetooth ( Optional ) |
Other I/O Interface |
1 x Power Switch |
Display |
|
LCD Size |
21.5" ( 16:9 ) |
Resolution |
1920 x 1080 ( FHD ) |
Brightness (cd/m²) |
400 |
Contrast Ratio |
1000:1 |
Backlight MTBF |
50000 hrs |
Viewing Angle |
89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D ) |
Touch screen |
|
Touch Type |
5 wire Resistive touch |
Surface Hardness |
≥3H |
Power |
|
Power Adapter |
1 x Optional AC/DC 12V/5A , 60W |
Power Input |
2-pin Terminal Block Connector with Power Input 12~24VDC |
Power Consumption |
≦45W |
Physical |
|
Material |
Aluminum Alloy Shell |
Mounting |
Stand / Wall / VESA / Panel |
Dimension (W x H x D) |
535 x 327 x 42 mm |
Packing Size |
630 x 190 x 480 mm |
Weight (Net) |
9 KG |
Environment |
|
Operating Temperature |
-20~70°C ( -4~158°F ) |
Storage Temperature |
-30~80°C (-22~176°F) |
Relative Humidity |
5%~95%@40°C, non-condensing |
Vibration Protection |
1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
IP Level |
IP67 / IP69K |
EMC |
CE, FCC, ROHS |
About us
QYT industrial tablet computer is an industrial control computer specially used in the industry. Its basic performance and compatibility are almost the same as those of commercial computers, but industrial tablet computers pay more attention to the stability in different environments, such as beverage production line control, Automobile production line control, etc., require stability in harsh environments, such as dustproof, waterproof, antistatic, etc. The industrial panel computer does not require the highest performance at present, but only meets the requirements of the system, and must meet the reliability requirements and stability in the industrial environment. Otherwise, if the computer crashes when used in the production line, it may cause serious losses. Therefore, the industrial panel computer The standard values required by the computer must meet strict specifications and scalability.
