Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc

Certification
China QYT industry Co.,Ltd certification
China QYT industry Co.,Ltd certification
Customer Reviews
I use these industrial embedded box pc for machine control, they work great, and the fanless design is a huge plus in an environment where small metal particles are everywhere. The Wi-Fi reception is excellent, continuous work, wide voltage DC 9V~36V and reverse connection protection, as in description, everything works perfect, good communication.

—— Lacroix Philippe

Great industrial touch panel pc easy to work with and well constructed, fast delivery, with windows 10, TPM2.0 Provide a secure encryption key. our equipment needed multiple USB inputs . And if I need to ever control any external devices by RS232 or RS422 or RS485 ports opens up so many possibilities. nice product, I highly recommend it.

—— Roy Smith

I'm Online Chat Now

Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc

Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc
Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc

Large Image :  Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc

Product Details:
Place of Origin: Shenzhen, China
Brand Name: QYT
Certification: CE, FCC, RoHS
Model Number: EFIC-1000PA
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Foam + Carton
Delivery Time: 3-10 Business Days
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Set/Sets per Month

Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc

Description
CPU: Intel Core I5-6200U Dual Core 2.5GHz Memory: DDR4L 2133MHz 4GB, Up To 16GB
Harddisk: 32G SSD / (64G / 128G / 250G / 500G SSD) Optional I/O Port: VGA/HD-MI/LAN/USB/COM
Power Input: DC 12V~24V / Optional(+9V~36V) Operating System: Win7/8/10/Linux/Ubuntu
Power Consumption: ≤30W Working Time: 7*24h
High Light:

X86 Intel i5 compact industrial pc

,

32G compact industrial pc

,

i5 windows embedded pc

Customized Intel I5 X86 Run Windows Fanless Industrial Embedded Box Pc With 2*RJ45

Feature

Fanless mini PCs are industrial grade computing solutions designed and built to withstand deployment in challenging environments to manage workloads for processing, storage, and connectivity. Fanless mini computers are great for deployment in challenging environments because they are passively cooled, utilize solid-state drives, and can be configured using wide temperature range components. All of these key features result in a ruggedized, fanless mini computing solution that has no moving parts and is resistant to dust, dirt, shocks, vibrations, and extreme temperatures.



1. Aluminium alloy shell


2. Intel Core i5-6200U Dual Core 2.5GHz

3. Multi ports for option: VGA/HD-MI/LAN/USB/COM

4. Operating System: Win7/8/10/Linux/Ubuntu

5. DC12V~24V Input,(+9V~36V)wide voltage input optional



EFIC-1000PA
System CPU Intel Core i5-6200U Dual Core 2.5GHz
L2 Cache 3MB
Chipsets Intel 6th Skylake-U SOC
Memory DDR4L 2133MHz 4GB, Up to 16GB
Harddisk 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
Graphics Intel HD Graphics 520
Network Intel® i211 1000 Mbps port
Audio Realtek ACL662 Audio controller
Operation System Windows7 / 8 / 10, Linux, Ubuntu, Debian
I / O VGA 1 x VGA / 1 x HD-MI
LAN 2 x LAN
USB 4 x USB2.0 / 2 x USB3.0
COM 4 x RS232
Wireless Network WiFi + Bluetooth ( Optional )
Other I/O Interface 1 x Power Switch
Institutional Material Aluminum Alloy Shell
Color Grey / Silver / Black ( optional )
VESA Mounting 208 x 100 mm / 208 x 60 mm
Product Dimension 220 x 145 x 62 mm
Packing Size 360 x 180 x 320 mm
Gross Weight 4.0 KG
Power and Environment Operating Temperature -10~60°C
Storage Temperature -20~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC 12V~24V / optional(+9V~36V)
Power Consumption ≦15W


Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc 0Customized X86 Intel I5 Compact Industrial Pc , 32G Fanless Windows Embedded Pc 1

Applications

Provide full control and communication functions:

1. Factory automation

2. Building automation

3. Intelligent road

4. Surveillance

5. Automobile devices

6. Medicare and health care

7. Gaming and gambling platform

8. Aviation and space





Our Advantage

1. Experience

QYT has more than 10 years rich experience in Industrial Computer/monitor filed.



2. Wide products line

7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android pc...etc.which have excellent work performane.



3. Customization functions

It offers rich of interface to meet csutomers needs.



4.Widely useage environment

QYT computer/monitor which is widly used for kitchen,food industry, boat...etc
