Product Details:
|
| Name: | 18.5'' Industrial All In One PC | Size: | 18.5 Inch ( 16:9 ) |
|---|---|---|---|
| Resolution: | 1920 X 1080 | CPU: | J1900/i3/i5 Optional |
| Memory: | DDR3L 1333MHz 4GB, Up To 8GB | Harddisk: | 1 X MSATA 128G SSD（250G / 500G / 1TB SSD) / 1 X 2.5" SATA |
| TPM 2.0: | YES | OS: | Windows 7 / 10 / 11， Linux, Ubuntu |
| High Light: | 18.5Inch Industrial All In One PC,Front IP65 All In One PC,RS232 Industrial Panel PC |
||
18.5Inch Industrial All In One PC HMI Panel J1900 CPU Front IP65
18.5Inch Industrial All In One PC J1900 front IP65 with 3*LAN 2*RS485/RS232
18.5'' Industrial All In One PC selling point
1. It adopts Intel® Bay Trail Celeron J1900 CPU, built-in DDR3L SODIMM memory module, and has various interfaces. The overall platform has stronger graphics processing capability, faster processing speed, and full-size touch screen operation. This product can be expanded with PCI and PCI-E slots, which can be installed and removed independently.
2. 24-hour product testing to ensure product quality and details. Product appearance customization, accept new product development and design
3. PC Windows 7 / 10 / 11, Linux, Ubuntu operating system optional, capacitive or infrared touch optional, ten-finger touch or multi-function touch
5. Factory price, competitive price
| PPC-J185WAC | |
| System | |
| CPU | Intel® Bay Trail Celeron J1900 Quad-core 2.0GHz , TDP 10W |
| L2 Cache | 2MB |
| System Chipset | Integrated with Intel® SoC |
| Memory | DDR3L 1333MHz 4GB, Up to 8GB |
| Harddisk | 1 x mSATA 128G SSD(250G / 500G / 1TB SSD) / 1 x 2.5" SATA |
| Graphics | Intel HD Graphics |
| Network | Intel® I211-AT GbE LAN |
| Audio | Realtek ACL662 Audio controller |
| TPM | TPM 2.0 |
| Watchdog Timer | Software Programmable Supports 1~255 sec. System Reset |
| Operation System | Windows 7 / 10 / 11, Linux, Ubuntu |
| I / O | |
| VIDEO | 1 x H-DMI |
| LAN | 2 x LAN (10/100/1000 Mbps) |
| USB | 3 x USB2.0 / 1 x USB3.0 |
| COM | 2 x RS-232 / 422 / 485 |
| Audio | 1x Audio_out & Mic_in |
| Wireless Network | Optional (WiFi / Bluetooth / 4G ) |
| Display | |
| LCD Size | 18.5" ( 16:9 ) |
| Resolution | 1920 x 1080 ( FHD ) |
| Brightness (cd/m²) | 350 cd/m2 |
| Contrast Ratio | 1200:1 |
| Backlight MTBF | 50000 Hr (min.) |
| Viewing Angle | 85 / 85 / 85 / 85 (CR≥10) ( L / R / U / D ) |
| Touch screen | |
| Touch Type | 10 point PCAP |
| Surface Hardness | ≥7H |
| Power | |
| Power Adapter | 1 x Optional AC/DC 12V/5A , 60W |
| Power Mode | Support AT, ATX Mode |
| Power Input | 2-pin Terminal Block Connector with Power Input 9~36VDC |
| Power Protection | OVP (Over Voltage Protection) OCP (Over Current Protection) RPP(Reverse Polarity Protection) |
| Power Consumption | ≦30W |
| Physical | |
| Material | Aluminum alloy panel, anodized treatment |
| Mounting | Stand / Wall / VESA / Panel |
| Dimension (W x H x D) | 466 x 287 x 60 mm |
| Cut-out Size | 452 x 273 mm |
| Packing Size | 500 x 180 x 450 mm |
| Weight (Net) | 4.9 KG |
| Environment | |
| Operating Temperature | -20~70°C ( -4~158°F ) |
| Storage Temperature | -30~80°C (-22~176°F) |
| Relative Humidity | 5%~95%@40°C, non-condensing |
| Vibration Protection | 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
| IP Level | Front Panel IP66 |
| EMC | CE, FCC,ROHS |
Applications
The 18.5'' Industrial All In One PC is composed of an aluminum alloy casing, which can meet the heat dissipation requirements and effectively prevent dust from entering the device, ensuring a more stable operation of the device. Installation methods include embedded, VESA cantilever and desktop brackets.
This industrial tablet computer is widely used in smart express cabinets, logistics or industrial automation and other fields.
Our advantage:
1). More than ten years of experience in R&D and manufacturing of industrial tablet products.
2). In stock, to provide you with the shortest delivery time.
3). Passed CE, ROHS, FCC and other international certifications, the quality is guaranteed.
4). Strong quality control system, 72-hour aging and testing process to ensure that the product qualification rate reaches more than 99.9%.
