15 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45

Certification
China QYT industry Co.,Ltd certification
China QYT industry Co.,Ltd certification
Customer Reviews
I use these industrial embedded box pc for machine control, they work great, and the fanless design is a huge plus in an environment where small metal particles are everywhere. The Wi-Fi reception is excellent, continuous work, wide voltage DC 9V~36V and reverse connection protection, as in description, everything works perfect, good communication.

—— Lacroix Philippe

Great industrial touch panel pc easy to work with and well constructed, fast delivery, with windows 10, TPM2.0 Provide a secure encryption key. our equipment needed multiple USB inputs . And if I need to ever control any external devices by RS232 or RS422 or RS485 ports opens up so many possibilities. nice product, I highly recommend it.

—— Roy Smith

I'm Online Chat Now

15 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45

15 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45
15 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45 15 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45 15 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45

Large Image :  15 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45

Product Details:
Place of Origin: Guangdong, China
Brand Name: QYT
Certification: CE, FCC, RoHS IP65
Model Number: PPC-5015SAC
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Packaging Details: Foam + Carton
Delivery Time: 3-7 Work Days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 5000 Set/Sets per Month

15 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45

Description
Panel Size: 15" LED Resolution: 1024*768
CPU: Intel Core I5-8265U Dual Core 1.6GHz Memory: DDR4L 2400MHz 4GB, Up To 32GB
Harddisk: 1 X MSATA 64G SSD / (128G / 250G / 500G SSD) Optional I/O: 1xH-DMI,2xLAN,3xUSB2.0/1xUSB3.0,4xRS232/2x(RS232/422/485)
TPM: TPM2.0 Touchscreen: Multi-Touch PCAP
Operation System: Windows 10 / Linux, Ubuntu, Debian Display Brightness: 350 Cd/m2
High Light:

15 Inch Industrial Touch Panel PC

,

6 COM Industrial Touch Panel PC

,

RS232 panel mount touch screen pc

15 Inch Panel Mount Touch Screen Pc 6 COM RS232 RS422 RS485 USB RJ45 HDM-I TPM2.0

Feature:
1. 15" TFT LED, resolution 1024 x 768, Multi-Touch PCAP


2. Intel Core i5-8265U Dual Core 1.6GHz

3. I/O: 1xH-DMI,2xLAN,3xUSB2.0/1xUSB3.0,4xRS232/2x(RS232/422/485),4G/WiFi/Bluetooth ( Optional )

4. Operating System: Win7/8/10/Linux/Ubuntu

5. DC IN 9V~36V

6. Wide range: -20°C to 70°C working temperature range.

7. VESA Mounting: 100 x 100 mm

8. 1000nits sunlight readable optional

9. TPM2.0

10. 8KV Static Electricity & 600W TVS Surge Protection


Application
Ticket machine
Out fare turnstile gates
SMArt Lockers parcel locker
On vessel
Stereo garage
Security monitoring
Self serve kiosk
Automatic pay station machine


Specification
PPC-5015SAC
SystemCPUIntel Core i5-8265U Dual Core 1.6GHz
L3 Cache6MB
MemoryDDR4L 2400MHz 4GB, Up to 32GB
Harddisk1 x mSATA 64G SSD / (120G / 250G / 500G SSD) Optional
GraphicsIntel HD Graphics 620
NetworkIntel® I211-AT GbE LAN
AudioRealtek ACL662 Audio controller
TPMTPM 2.0
Operation SystemWindows 10 / Linux, Ubuntu, Debian
I / OHDMI1 x H-DMI
LAN2 x LAN
USB4 x USB 3.0
COM4 x RS-232 / 2 x(RS-232 / 422 / 485)
Audio1x Audio_out & Mic_in
Wireless NetworkWiFi / Bluetooth ( 4G / Optional )
Other I/O Interface1 x Power Switch
LCD PanelPanel Size15" LED
Resolution1024 x 768
Aspect Ratio4:3
Display Brightness350 cd/m2
Contrast Ratio1000:1
Backlight Lifetime50000 Hr (min.)
Viewing Angle89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
Touch screenTouch Screen TypeMulti-Touch PCAP
Transmittance>90%
Response Time<5ms
Surface Hardness≥7H
Supply Voltage5.0V DC
Touch Life≧ 3000W
InstitutionalMaterialHigh-strength Al-alloy, support IP65
ColorGray
VESA MountingVESA: 100 x 100 mm
Waterproof RateIP65
Product Dimension361 x 285 x 60 mm
Cut-out Size347 x 271 mm
Packing Size460 x 180 x 400 mm
Gross Weight7 KG
Power and EnvironmentOperating Temperature-20~70°C
Storage Temperature-30~80°C(-22~176°F)
Relative Humidity5%~95%@40°C, non-condensing
Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power SupplyAC 100 - 240V~50/60Hz,1.5A
Working VoltageDC IN 9V~36V
Power Consumption≦35W


15 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45 015 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45 115 Inch Panel Mount Industrial Touch Panel PC 6 COM RS232 RS422 RS485 USB RJ45 2
