15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu

Certification
China QYT industry Co.,Ltd certification
China QYT industry Co.,Ltd certification
Customer Reviews
I use these industrial embedded box pc for machine control, they work great, and the fanless design is a huge plus in an environment where small metal particles are everywhere. The Wi-Fi reception is excellent, continuous work, wide voltage DC 9V~36V and reverse connection protection, as in description, everything works perfect, good communication.

—— Lacroix Philippe

Great industrial touch panel pc easy to work with and well constructed, fast delivery, with windows 10, TPM2.0 Provide a secure encryption key. our equipment needed multiple USB inputs . And if I need to ever control any external devices by RS232 or RS422 or RS485 ports opens up so many possibilities. nice product, I highly recommend it.

—— Roy Smith

I'm Online Chat Now

15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu

15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu
15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu 15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu 15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu

Large Image :  15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu

Product Details:
Place of Origin: Shenzhen, China
Brand Name: QYT
Certification: CE, FCC, RoHS, IP65
Model Number: PPC-C156WAC
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Foam + Carton
Delivery Time: 3-10 Business Days
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Set/Sets per Month

15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu

Description
Name: 15.6 Inch Touch Industrial Panel PC LCD Size: 15.6" ( 16:9 )
Resolution: 1920 X 1080 ( FHD ) CPU: Intel® Elkhart Lake Celeron J6412 Quad-core 2.0GHz , TDP 10W
TPM 2.0: YES Operation System: Windows 10 / 11, Linux, Ubuntu
Wireless Network: Support 4G/5G/WIFI/BLUETOOTH DC: 9-36V
High Light:

Ubuntu Industrial Touch Panel PC

,

Linux Industrial Touch Panel PC

,

J6412 Industrial Panel PC

15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu



15.6 inch J6412 Pcap Touch Industrial Panel PC TPM 2.0



15.6" Industrial Touch Panel PC
8"/10.1"/10.4"/12.1"/15"/15.6"/17"/19"/21.5" industrial touch panel PC optional

Product features of 15.6" Industrial Touch Panel PC: Full flat resistive touch screen (optional capacitive screen), front panel IP65 protection level; optional J6412/X6425E/J1900/i3/i5/i7 processor; dual INTEL Gigabit Ethernet ports; onboard DDR3L 4GB/DDR4 8GB memory/optional SODIMM slot; support LCD+HDMI synchronous/asynchronous dual display mode; low power consumption without fan; 9 ~ 36V wide voltage input; one-button recovery system function.



PPC-C156WAC
System
CPU Intel® Elkhart Lake Celeron J6412 Quad-core 2.0GHz , TDP 10W
L2 Cache 1.5MB
System Chipset Integrated with Intel® SoC
Memory DDR4L 3200MHz 4GB, MAX 32GB
Harddisk 1 x M.2 120G SSD ( 250G / 500G / 2TB SSD) / 1 x 2.5" SATA
Graphics Intel® UHD Graphics for 10th Gen Intel® Processors
Network Intel® 225-V GbE LAN
Audio Realtek ACL897 Audio controller
TPM TPM 2.0
Watchdog Timer Software Programmable Supports 1~255 sec. System Reset
Operation System Windows 10 / 11, Linux, Ubuntu
I / O
VIDEO 1 x H-DMI
LAN 3 x LAN (10/100/1000/2500 Mbps)
USB 4 x USB 3.0
COM 2 x RS-232 / 422 / 485
Audio 1x Audio_out & Mic_in
Wireless Network Optional (WiFi / Bluetooth / 4G / 5G )
Display
LCD Size 15.6" ( 16:9 )
Resolution 1920 x 1080 ( FHD )
Brightness (cd/m²) 450
Contrast Ratio 1000:1
Backlight MTBF 50000 hrs
Viewing Angle 89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
Touch screen
Touch Type 10 point PCAP
Surface Hardness ≥7H
Power
Power Adapter 1 x Optional AC/DC 12V/5A , 60W
Power Mode Support AT, ATX Mode
Power Input 2-pin Terminal Block Connector with Power Input 9~36VDC
Power Protection OVP (Over Voltage Protection)
OCP (Over Current Protection)
RPP(Reverse Polarity Protection)
Power Consumption ≦30W
Physical
Material Aluminum alloy panel, anodized treatment
Mounting Stand / Wall / VESA / Panel
Dimension (W x H x D) 400 x 250 x 60 mm
Cut-out Size 386 x 236 mm
Packing Size 460 x 180 x 400 mm
Weight (Net) 4.1 kg
Environment
Operating Temperature -20~70°C ( -4~158°F )
Storage Temperature -30~80°C (-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Protection 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
IP Level Front Panel IP66
EMC CE, FCC,ROHS



15.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu 015.6 Inch J6412 Industrial Touch Panel PC Windows Linux Ubuntu 1
