J6412 Fanless Mini Computer Industrial Box PC 3 Lan Port For Industrial Automation

J6412 Fanless Mini Computer Industrial Box PC 3 Lan Port For Industrial Automation
J6412 Fanless Mini Computer Industrial Box PC 3 Lan Port For Industrial Automation J6412 Fanless Mini Computer Industrial Box PC 3 Lan Port For Industrial Automation

Large Image :  J6412 Fanless Mini Computer Industrial Box PC 3 Lan Port For Industrial Automation

Product Details:
Place of Origin: Shenzhen, China
Brand Name: QYT
Certification: CE, FCC, RoHS
Model Number: EFIC-2000CA
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Foam + Carton
Delivery Time: 3-10 Business Days
Payment Terms: T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
Supply Ability: 5000 Set/Sets per Month

J6412 Fanless Mini Computer Industrial Box PC 3 Lan Port For Industrial Automation

Description
CPU: Intel Celeron J6412 Quad Core 2.0GHz Memory: DDR4L 3200MHz 4GB, Up To 32GB
Harddisk: 1 X M.2 120G SSD / ( 250G / 500G SSD) Optional / 1 X 2.5" SATA I/O Port: 1*HDMI, 1*DP, 3*LAN, 10*USB, 6*COM
Power Input: DC 9V~36V Voltage Input Operating System: Windows 10, Linux, Ubuntu, Debian
Type: Fanless Mini Computer J6412 Warranty: 12 Months
High Light:

J6412 Fanless Mini Computer

,

Industrial Automation Fanless Mini Computer

,

Fanless Industrial Box Pc

Fanless Mini Computer J6412 Box Pc With 3 Lan Port Industrial Automation

Durable and resistant to harsh environments. In order to make industrial computers adapt to the harsh and harsh application environment, manufacturers especially strengthen their performance in terms of waterproof, dustproof and shockproof when producing industrial computers. Therefore, the industrial computer has the characteristics of sturdiness and durability, allowing users to use it smoothly in harsh environments.



Industrial Fanless Mini PC Features:

1. Intel 12th Celeron J6412 2.0GHz Fanless Configuration
2. 3*Gigabit Ethernet Ports, Wake on LAN and PXE Supported
3. 2*RS-232 / 4*RS-232 / 422 / 485 (Optional), 1*WiFi / Bluetooth / 4G / 5G Optional
4. TPM 2.0 Support For Maximum Security
5. Work temperature -20 ° C to 70 ° C
6. DC 9V~36V Input



EFIC-2000CA
System
CPU Intel Celeron J6412 Quad Core 2.0GHz
L2 Cache 1.5 MB
Chipsets Intel® SoC
Memory DDR4L 3200MHz 4GB, Up to 32GB
Harddisk 1 x M.2 120G SSD / ( 250G / 500G SSD) Optional / 1 x 2.5" SATA
Graphics Intel® UHD Graphics for 10th Gen Intel® Processors
Network Intel® 225-V GbE LAN
Audio Realtek ACL662 Audio controller
TPM TPM 2.0
Operation System Windows 10, Linux, Ubuntu, Debian
I / O
VIDEO 1 x DP / 1 x HD-MI
LAN 3 x LAN
USB 6 x USB2.0 / 4 x USB3.0
COM 2 x RS-232 / 4 x RS-232 / 422 / 485
DIO DIO 8 Bits ( 4 In / 4 Out ) Optional
Audio 1x Audio_out & Mic_in
Wireless Network WiFi / Bluetooth ( 4G / 5G Optional )
Power Mode Switch AT/ATX
Other I/O Interface 1 x Power Switch
Institutional
Material Aluminum Alloy Shell
Color Grey / Silver / Black ( optional )
VESA Mounting 208 x 100 mm / 208 x 60 mm
Product Dimension 220 x 145 x 62 mm
Packing Size 360 x 180 x 320 mm
Gross Weight 4.0 KG
Power and Environment
Operating Temperature -20~70°C
Storage Temperature -20~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC 9V~36V
Power Consumption ≦15W


J6412 Fanless Mini Computer Industrial Box PC 3 Lan Port For Industrial Automation 0J6412 Fanless Mini Computer Industrial Box PC 3 Lan Port For Industrial Automation 1J6412 Fanless Mini Computer Industrial Box PC 3 Lan Port For Industrial Automation 2

Based on the cloud computing service center, establish a unified monitoring platform that can carry all bridges in the area, adopt industrial design, deploy various intelligent sensors, monitoring devices, network access equipment, etc. to acquire and transmit data on the whole bridge, and use platform big data analysis and professional algorithms. Fanless Mini Computer provides strong data support for bridge maintenance, changes the previous manual inspection mode of bridge maintenance, and further improves the informatization and intelligence level of urban bridge maintenance.
